NonInvasive Blood Pressure System for Rodents for Physiology Lab

Easy and reliable system for measuring systemic blood pressure and cardiovascular parameters in rodents without invasive catheterization. The system continuously monitors pulse signal and cuff pressure and automatically determines systolic, diastolic and mean blood pressure along with heart rate. It supports repeated measurements on the same animal and provides analog signal output for recording cuff pressure and pulse signals through a computer-based data acquisition system. A warm environment is recommended for accurate blood pressure measurement. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Dimensions of Control Unit :

• 360 (W) × 340 (D) × 120 (H) mm

Dimensions of Standard and Complete Control Units :

• 60 (W) × 340 (D) × 170 (H) mm

Computer Requirements :

• PC with compatible Windows operating system when data acquisition software is used

Power Supply :

• 220/110 VAC, 50/60 Hz

Certifications :

• CE compliant

Parameters Measured :

• Systolic blood pressure
• Diastolic blood pressure
• Mean blood pressure
• Heart rate

Basic Unit Includes :

• Control unit with LCD display
• Pressure and pulse BNC analog signal output
• RS-232 serial port
• Cables
• Spare fuses
• Instruction manual

Standard Unit Includes :

• All components of the basic unit
• Internal raw data memory for up to 4,000 successive trials

Complete Unit Includes :

• All components of the standard unit
• Statistical calculations including average, deviation and number of samples for all animals
• Connection to a heater and scanner system for automatic measurement of up to 12 animals

Accessories :

• Data acquisition software
• Software for monitoring pressure and pulse wave signals
• Single or multiple animal heating units
• Pulse transducer and cuff
• Specimen holders

Animal Heating :

• A warm environment is important for accurate blood pressure measurements
• A warming chamber or automatic heater and scanner can provide a controlled heated environment
• Heating supports peripheral vasodilatation and helps isolate the animal from external noise

System Options :

• Basic configuration with RS-232 serial communication
• Standard configuration with internal memory
• Complete configuration with scheduled data acquisition and statistical calculations
• Mouse pulse transducer and cuff
• Rat pulse transducer and cuff
• Dog pulse transducer and pressure cuff
• Mouse and rat specimen holders
• Replacement cuff membranes

• Supports consecutive measurements on the same animal
• Analog signal output for recording cuff pressure and pulse signals on a PC
• Automated deflation for each animal to help minimize tail lesions
• Automated cuff inflation and deflation at a consistent rate
• Suitable for mice, rats and dogs
• Provides direct measurement values without linear regression calculations
• Supports traceable data recording using data acquisition software
• Evaluated parameters can be viewed online on the digital display
