Oxygenating System Options for Isolated Perfusion Systems for Physiology Lab

The Oxygenating System Option is designed for use with perfusion systems when the buffer is supplemented with albumin, fatty acids, washed erythrocytes, or other additives that result in foaming solutions. It adapts fiber oxygenators for use with compatible perfusion systems and supports oxygenation during experimental perfusion applications. A glass oxygenator can also be used with the system. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Oxygenation of foaming perfusion solutions
• Perfusion research
• Physiological research
• Experimental organ perfusion
• Use with buffers containing albumin, fatty acids, or washed erythrocytes

Fiber Oxygenator Features :

Membrane Material :

• MediSulfone

Priming Volume – D150 :

• 18 mL

Priming Volume – DP07HE :

• 49 mL

Active Oxygenating Surface Area – D150 :

• 0.22 m²

Active Oxygenating Surface Area – DP07HE :

• 0.7 m²

Reusable Cycles :

• Can be used 3 to 10 times

Oxygenating System for IH-SR and UP-100IH :

• Fiber Oxygenator Type D150, package of 5
• Holder for oxygenators
• Mounting kit for D150 fiber oxygenator
• Connection kit for D150 or DP07HE fiber oxygenator, containing five sets of tubing connectors

Oxygenating System for IH-5 :

• Fiber Oxygenator Type DP07HE, package of 5
• Holder for oxygenators
• Mounting kit for DP07HE fiber oxygenator
• Connection kit for D150 or DP07HE fiber oxygenator, containing five sets of tubing connectors

Additional Oxygenator Option :

• Glass oxygenator can also be used with the system

• Suitable for buffers supplemented with albumin
• Suitable for buffers containing fatty acids
• Suitable for buffers containing washed erythrocytes
• Suitable for other foaming additives
• Supports adaptation of fiber oxygenators for compatible perfusion systems
• Oxygenator holders and mounting kits provided according to configuration
• Connection kits include tubing connectors
• Fiber oxygenators can be used 3 to 10 times
