Paw and Tail Pressure Meter for Behavioral Research test

The Paw and Tail Pressure Meter is designed for performing the Randall-Selitto test in rodents by determining the animal's threshold response to pain induced through uniformly increasing pressure applied to the paw or tail. The system provides gradual and constant pressure increase at selectable rates using a step motor and sliding support with a distal stimulation tip. A pivoting stand helps prevent excessive pressure on the animal paw, while the control unit allows adjustment and resetting of the force transducer and selection of motor speed. The system can be used with rats and mice, with paw pressure commonly used in rats and tail pressure commonly used in mice. Two interchangeable stimulation tips, including pointed and flat tips, are provided for different mechanical stimulation areas. A remote foot switch enables rapid hands-free operation, while an automatic mechanism reverses the motor when the test is completed. Optional data transfer software can be used to visualize and export experimental data. Manufactured by Atico Export with a focus on reliable performance for animal pain and nociception research.

• Randall-Selitto pain threshold testing
• Paw pressure analgesia studies
• Tail pressure analgesia studies
• Nociception research
• Pain threshold assessment
• Analgesic drug screening
• Animal pain and behavioral research

Animal Compatibility :

• Rats and mice

Control Unit Dimensions :

• Width: 350 mm
• Depth: 350 mm
• Height: 130 mm

Stimulation Unit Dimensions :

• Width: 150 mm
• Depth: 210 mm
• Height: 166 mm

Maximum Stimulus :

• 999 g

Stimulus Resolution :

• 1 g

Pressure Application :

• Gradual and constant increase at selectable rates

Stimulation Tips :

• 1 pointed tip
• 1 flat tip

Material Composition :

• Methacrylate

Maximum Number of Stations :

• 1 per computer
• Multiple sets available by request

Power Requirements :

• 110/220 V, 50/60 Hz

Certification :

• CE

• Digital display
• Uniformly increasing pressure for pain threshold assessment
• Adjustable pressure increasing rate
• Suitable for paw and tail pressure testing
• Suitable for rats and mice
• Foot-switch control for hands-free operation
• Step-motor driven gradual pressure application
• Force transducer adjustment, balance and reset functions
• Two interchangeable stimulation tips
• Pointed and flat tips for different stimulation areas
• Pivoting stand helps prevent excessive pressure on the paw
• Automatic motor reversal at test completion
• Optional computer-based data visualization and data export
