Perfusate Deoxygenation Option for Isolated Perfusion Systems for Physiology Lab

The Perfusate Deoxygenation Option is designed for use with isolated perfused lung systems to deoxygenate blood or buffers containing proteins such as albumin or erythrocytes. The system uses fiber oxygenators with MediSulfone membrane materials and provides effective deoxygenating surface areas suitable for different perfusion system configurations. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Deoxygenation of blood
• Deoxygenation of protein-containing buffers
• Deoxygenation of albumin-containing buffers
• Deoxygenation of erythrocyte-containing solutions
• Isolated perfused lung studies
• Physiological and pharmacological research

Effective Surface Area :

• 0.25 m² (2,500 cm²)

Internal Diameter :

• 250 µm

Outer Diameter :

• 28 mm

Wall Thickness :

• 50 µm

Effective Fiber Length :

• 140 mm

Number of Fibers :

• 2,500

Fiber Material :

• MediSulfone Polysulfone, 50,000 Da

Ultrafiltration Rate :

• 5.5 mL/h/mmHg

Maximum Pressure :

• 500 mmHg

Sterilization :

• ETO sterilized

Priming Volume :

• 19 mL

Weight :

• 63 g

Housing Material :

• Polycarbonate

Full Length :

• 180 mm

Fiber Oxygenator Configuration – DP07HE :

Effective Surface Area :

• 0.7 m² (7,000 cm²)

Internal Diameter :

• 200 µm

Outer Diameter :

• 43 mm

Wall Thickness :

• 30 µm

Effective Fiber Length :

• 140 mm

Number of Fibers :

• 9,300

Fiber Material :

• High Flux PUREMA

Ultrafiltration Rate :

• 32 mL/h/mmHg

Maximum Pressure :

• 600 mmHg transmembrane pressure

Sterilization :

• ETO sterilized

Priming Volume :

• 49 mL

Weight :

• 140 g

Housing Material :

• Polycarbonate

Full Length :

• 180 mm

• Suitable for isolated perfused lung systems
• 19 mL priming volume for smaller system configurations
• 54 mL priming volume for larger system configurations
• MediSulfone membrane material for deoxygenating applications
• Effective deoxygenating surface area of 0.25 m²
• Effective deoxygenating surface area of 0.6 m² for larger system configuration as specified
• Fiber oxygenator systems supplied with connection and mounting accessories
• Stand-alone oxygenator holder included
• Suitable stand with triangular base and block clamp included
