Peristaltic Pump

Peristaltic Pump is a type of pump designed to ensure the precise transfer of liquids, particularly preferred in laboratory environments. This pump moves liquids by applying pressure on a flexible tube. As a result, the liquid is transferred without coming into contact with the pump mechanism, eliminating the risk of contamination.

WORKING PRINCIPLE :

The peristaltic pump moves liquid by applying pressure to the outside of a flexible hose. Rotating rollers or wheels compress the hose, pushing the liquid forward. Thanks to this operating principle, the liquid does not come into contact with the internal components of the pump.

Peristaltic pumps are widely used, especially in sample preparation processes requiring precise liquid transfer. They are ideal for dosing, mixing, or transferring liquids in the chemical, biotechnology, and pharmaceutical industries. Since pressure is applied to the outer surface of the hose, the liquid does not come into contact with the pump mechanism, eliminating the risk of contamination.

Timer Setting :

• 0.1 - 999 second

Power and Electricity :

• 50 W

Flow Rate :

• The pump has an adjustable flow rate ranging from 0.3 ml/min to 6000 ml/min. This adjustability provides precise flow control required for various applications.

Hose Compatibility :

• Compatible with silicone hoses having an inner diameter of 10 mm (ID °10) and an outer diameter of 15 mm (OD °15).

Solid Particles Handling :

• Recommended Maximum Solid Content : 35% (w/w)
• Recommended Maximum Particle Size : 350 microns

This peristaltic pump offers high performance and reliability in applications requiring accurate liquid transfer.
