Peristaltic Pump for Physiology Lab

The Peristaltic Pump for Physiology Lab offers accurate, reproducible, and easy-to-use fluid delivery for a wide range of dispensing applications. It consists of a control unit, motor drive, tubing cassette, and sample tubing. The remote motor drive can be separated from the controller to save space and facilitate operation inside incubators and fume hoods. The pump supports interchangeable motor drives, custom tubing, programmable flow profiles, and multiple control options. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Fluid dispensing
• Physiological research
• Experimental laboratory applications
• Incubator and fume hood applications
• Constant flow delivery
• Flow ramp applications
• Pulsatile flow delivery
• Concentration-based fluid delivery
• Pressure-controlled fluid delivery

Programmable Flow Profiles :

• Constant Flow
• Flow Ramps
• Pulsatile Flow
• Concentration Based Fluid Delivery

Available Motor Drives :

• P-70 drive: 0.001 to 70 mL/min
• P-230 drive: 0.001 to 230 mL/min
• P-1500 drive: 0.01 to 1,500 mL/min

Type :

• 8 rollers, 5 channels

Accuracy :

• ±1.0%

Back Pressure :

• 15 psi

Computer Interface :

• USB Type B

Control Box Dimensions, H × W × D :

• 20.7 × 13 × 9.6 cm (8.13 × 5.13 × 3.75 in)

Pump Head Dimensions, H × W × D :

• 11.5 × 25.4 × 11.8 cm (4.5 × 10 × 4.63 in)

Maximum RPM :

• 229 RPM

Flow Rate Range :

• 0.001 mL/min to 70 mL/min

Power :

• 100 to 250 VAC, 50/60 Hz

Protection Rating :

• IP23

Pump Configuration :

• Remote

Pump Voltage :

• 30 VDC, 1.67 A

Pump to Pump Communication :

• IEEE 1394

Reversible Flow :

• Yes

TTL Connector :

• 15-pin D-sub

Tubing ID :

• 0.13 to 2.79 mm (0.005 to 0.110 in)

Weight :

• 4.7 kg (10.5 lb)

• LCD color touch screen with intuitive icon interface for easy operation
• Remote motor drive design suitable for use inside incubators and fume hoods
• Interchangeable pump heads and motor drives
• Tubing size library stored in pump memory to minimize setup time
• Supports custom tubing for flexible operation
• Single-channel or combined-channel flow rate setting
• Continuous pump operation at a set flow rate
• Timed dispense for dispensing at a set flow rate for a fixed time
• Volume dispense for delivering a fixed volume
• Footswitch control
• Analog control
• Bidirectional fluid delivery
• USB computer interface
• Remote start/stop control
• Communication with external devices through 15-pin I/O
• Constant pressure operation using a pressure transducer
• User-generated methods can be saved and recalled from pump memory
• Rapid calibration routine for optimizing flow accuracy
• CE, ETL (UL, CSA), WEEE, EU RoHS and CB Scheme approved
• 2-year warranty
