Plethysmometer for Behavioral Research test

The Digital Water Plethysmometer is designed for accurate measurement of small volume changes and is commonly used to monitor experimentally induced inflammatory responses in rodents and to screen potential anti-inflammatory or anti-oedema properties of pharmacological substances. The volume transducer consists of two interconnected Perspex tubes filled with a conductive solution, with a platinum electrode in each chamber. When the animal paw is immersed in the measuring tube, water displacement produces a change in conductance between the electrodes, which is detected by the control unit and displayed as the measured volume displacement with a resolution of 0.01 ml. The system provides automatic zero adjustment between successive readings, eliminating the need for intermediate manual adjustments. A remote foot switch enables rapid hands-free measurement control, while optional data transfer software allows collected data to be visualized and exported to a computer for further analysis. Manufactured by Atico Export with a focus on reliable performance for animal inflammatory and pharmacological research.

• Inflammation response studies
• Paw edema measurement
• Anti-inflammatory drug screening
• Anti-oedema pharmacological studies
• Rodent inflammatory research
• Experimental pharmacology
• Small volume displacement measurement

Species :

• Mouse
• Rat
• Rat

Control Unit Dimensions (W × D × H) :

• 280 × 280 × 110 cm

Stimulation Unit Dimensions (W × D × H) :

• 230 × 220 × 300 cm

Power Supply :

• 220/110 V, 50/60 Hz

Resolution :

• 3 digits; 0.01 steps

Cell Volume :

• 1 ml
• 3 ml
• 5 ml

Cell Inner Diameter :

• 12 mm
• 20 mm
• 24 mm

Measurement Principle :

• Water displacement and conductance change between platinum electrodes

Cell Options :

• 1 ml cell with electrode
• 3 ml cell with electrode
• 5 ml cell with electrode

• Accurate measurement of small volume changes
• Suitable for monitoring inflammatory responses in rodents
• Automatic zero adjustment between successive readings
• Check-solution status function
• Foot-switch control for rapid hands-free operation
• Digital display of measured volume displacement
• 0.01 ml measurement resolution
• Conductive solution-based volume transducer
• Platinum electrodes for conductance measurement
• Optional computer-based data visualization and data export
• Suitable for anti-inflammatory and anti-oedema drug screening
