Rat Activity Wheel with Triple Lickometer for Physiological Research Instrumentation

The Rat Activity Wheel with Triple Lickometer is designed for long-term circadian rhythm and general activity studies in rats or similar-sized animals. The system combines a rat activity wheel with three lickometer drinking stations for simultaneous monitoring of locomotor activity and licking behavior. The stainless steel wheel has a 14-inch (35.56 cm) internal diameter and operates with less than 6 grams of turning force. Its durable running surface uses stainless steel rods arranged for animal comfort and long-term use. The lickometer section includes a perforated stainless steel floor while retaining space for standard bedding, along with three 50 ml bottles fitted with sipper tubes. Bottles can be removed without disconnecting wires, and cover plates allow studies requiring fewer than three active tubes. An easily removable stainless steel food hopper is included. Manufactured by Atico Export for reliable performance in rodent activity, circadian rhythm, drinking behavior and behavioral research.

• Circadian rhythm studies
• General activity monitoring
• Voluntary running studies
• Drinking and licking behavior studies
• Food and water intake research
• Rodent behavioral research
• Long-term activity studies

Tub Dimensions :

• 16 × 20 × 8.25 in H
• 40.64 × 50.80 × 20.96 cm

Overall Dimensions :

• 16 × 20 × 16.5 in H
• 40.64 × 50.80 × 41.91 cm

Weight :

• 13.2 lbs (5.99 kg)

Wheel Diameter :

• 14 in (35.56 cm) I.D.

Wheel Width :

• 4.3 in (10.92 cm) internal

Run Distance :

• 1.10 m/revolution

Recommended Animal Weight :

• Up to 500 grams

Wheel Rim :

• 0.036 in (0.91 mm) stainless steel

Running Surface Rod Diameter :

• 0.0625 in (1.5875 mm)

Running Surface Rod Spacing :

• 0.3125 in (7.9375 mm) centers

Running Surface Gap :

• 0.25 in (6.35 mm)

Wheel Turning Resistance :

• Less than 6 g

Lickometer Tubes :

• 50 ml calibrated tube
• 6 mm rubber stopper
• 4 in bent sipper with ball bearing

Lickometer Configuration :

• Three active lickometer tubes
• Separate lickometer/counter required for each active lick tube

Food Hopper :

• Stainless steel
• Easily removable

Activity Wheel Counter :

• Ordered separately

• Designed for long-term circadian rhythm studies
• Suitable for general activity studies
• Suitable for rats and similar-sized animals
• Integrated triple lickometer configuration
• Three 50 ml drinking bottles with sipper tubes
• Perforated stainless steel floor for lickometer circuits
• Space available for standard bedding
• Bottles can be removed without disconnecting wires
• Cover plates included for studies requiring fewer than three tubes
• Easily removable stainless steel food hopper
• Durable stainless steel activity wheel
• Low wheel turning resistance
• Designed for animal comfort and easy maintenance
