Rat Misstep Wheel with Living Chamber for Physiological Research Instrumentation

The Rat Misstep Wheel with Living Chamber is designed for gait studies and general activity studies in rats or similar-sized animals. The polycarbonate running wheel features removable anodized aluminum rods, allowing individual rods or a series of rods to be removed to create misstep configurations for gait research. The rods are securely attached to the wheel rims and can be removed by loosening the retaining screws. The wheel provides a large internal diameter and low turning resistance for comfortable animal movement. The autoclavable polycarbonate tub and bottle, stainless steel lid and food hopper support convenient cleaning and maintenance. The sensor/counter component can be removed without tools, while the wheel portion can also be removed easily for cleaning. Manufactured by Atico Export with a focus on reliable performance, animal well-being and convenient maintenance for rodent gait and behavioral research.

Tub Dimensions :

• 16 × 20 × 8.25 in H
• 40.64 × 50.80 × 20.96 cm

Overall Dimensions :

• 16 × 20 × 16.5 in H
• 40.64 × 50.80 × 41.91 cm

Weight :

• 14.65 lbs (6.65 kg)

Wheel Diameter :

• 13.31 in (33.81 cm) internal

Run Distance :

• 1.06 m/revolution

Rod Quantity :

• 82 removable rods

Rod Diameter :

• 0.188 in (4.8 mm)

Rod Material :

• Anodized aluminum

Rod Spacing :

• 0.52 in (13.1 mm) centers

Rod Gap :

• 0.33 in (8.3 mm)

Turning Resistance :

• Less than 8 g

Recommended Animal Weight :

• Up to 500 grams
