Rodent Shocker for Behavioral Research test

The Rodent Shocker is designed for reliable electrical induction of seizures in small experimental animals such as mice and rats for testing anticonvulsant drugs and conducting electrical kindling studies. The system delivers a sinusoidal alternating current through suitable stimulation electrodes to produce controlled clonic and/or tonic seizure responses. The stimulation current and duration can be adjusted according to the experimental protocol, while the delivered current is displayed after stimulation. Two electrode configurations are available for eye or ear stimulation. A constant-current, fully floating output and multiple safety features help control the stimulation process, while a foot switch allows convenient operation. The system is manufactured by Atico Export for controlled performance in animal seizure and pharmacological research.

• Anticonvulsant drug screening
• Electrically induced seizure studies
• Epilepsy research
• Electrical kindling studies
• Pharmacological testing of antiepileptic therapies
• Rodent neuroscience research
• Experimental seizure models

Animal Compatibility :

• Mice
• Rats

Stimulation Frequency :

• 50 Hz
• 60 Hz

Stimulus Duration :

• 0.1 to 9.9 seconds
• Adjustable in 0.1-second steps

Stimulus Energy :

• Up to 75 W

Output Type :

• Constant current
• Fully floating output
• Current set using a 10-turn potentiometer
• Current displayed digitally

Standard Output Current :

• 0 to 300 mA at 250 V
• 0 to 150 mA at 500 V
• 0 to 100 mA at 750 V

Low Current Output :

• 0 to 30 mA at 250 V
• 0 to 30 mA at 500 V
• 0 to 20 mA at 750 V

Electrode Options :

• Ear electrodes for mice and rats
• Eye electrodes for mice and rats
• Electrodes are purchased separately

Ear Electrode Construction :

• Two insulated nickel-plated clips
• Contact points formed by chlorided silver discs
• Disc diameter: 6 mm
• Disc thickness: 1 mm

Eye Electrode Construction :

• Bipolar electrode
• Stainless-steel buttons
• Thin leather pads at the forceps ends
• Pads require moistening with saline solution or electrode gel before use

Safety System :

• Stimulus triggering requires sequential operation of separate safety controls
• Output is electrically floating and has no connection to ground
• Current flows only between the two electrodes
• Output automatically switches off when electrodes are not connected to an object
• Output automatically switches off if electrode-tissue contact is interrupted
• Output sockets are protected against contact

Foot Switch :

• Supplied for stimulus triggering

Power Supply Options :

• 110 VAC, 60 Hz
• 220 VAC, 50 Hz

Dimensions :

• 150 × 260 × 360 mm (H × W × D)

Weight :

• 5 kg

• Suitable for mice and rats
• Designed for anticonvulsant drug testing
• Suitable for electrical kindling studies
• Sinusoidal 50 Hz or 60 Hz stimulation
• Adjustable stimulation current
• Adjustable stimulus duration
• Constant-current, fully floating output
• Digital display of selected current
• Two electrode options for eye or ear stimulation
• Foot switch operation
• Floating output with no connection to ground
• Automatic output shut-off if electrodes are disconnected or tissue contact is interrupted
• Sequential safety controls for stimulus triggering
• Protected output sockets
• Suitable for controlled seizure induction studies
