Servo Controller Module for Perfusion Pressure Regulation and Indirect Flow Measurement for Physiology Lab

Servo Controller Module for Perfusion Pressure Regulation and Indirect Flow Measurement for Physiology Lab designed for perfusion control of isolated organs by regulating the speed of a peristaltic pump. It maintains perfusion at either constant pressure or constant flow and allows selection between the two operating modes using a switch. The module also calculates and displays perfusion flow from pump speed, providing an indirect flow measurement method. It includes an analog output corresponding to pump speed for continuous flow recording through a computer-based data acquisition system. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Function :

• The built-in PID controller regulates the speed of the connected peristaltic pump
• Higher pump speed produces higher pressure in the perfused organ
• In constant-flow mode, the controller regulates pump speed to control flow
• Flow varies linearly with pump speed
• In constant-pressure mode, the user defines the desired pressure setpoint
• The controller automatically adjusts pump speed until the setpoint pressure is reached and maintained
• When pressure is below the setpoint, the controller increases pump speed
• When pressure is above the setpoint, the controller decreases pump speed
• Closed-loop control continuously maintains the selected pressure level
• Since delivered flow rate is proportional to pump speed, the module calculates and displays flow directly from pump speed
• Flow calculated from pump speed is classified as indirect flow measurement

Required Components :

• Measuring system with pressure transducer and amplifier
• Peristaltic pump suitable for external analog control
• Pump with 0 to 5 V or 0 to 10 V analog input
• Suitable pump tubing
• Connection cable for the selected peristaltic pump
• Compatible bridge amplifier module
• Compatible modular housing

Technical Specifications :

• Actual value input: 0 to 10 V via system bus
• Ambient conditions: Laboratory indoor use
• Connector: DIN 41612, 96-pin VG
• Construction: Plug-in module for modular system
• Control gain: 1 to 50, adjustable
• Control voltage: 0 to 10 V for pump operation
• Derivative factor: 0.1 to 100, adjustable
• Digital indication: -1999 to +1999
• Digital indication selection: Actual value, setpoint or control output signal
• Function: Electronic PID controller for physiological and pharmacological research
• Integral factor: 0.05 to 10, adjustable
• Module width: 2-slot unit
• Power supply: 5 V, 0.3 A from system bus
• Recorder output: 0 to 10 V, BNC socket
• Setpoint: 0 to 5 V, adjustable
• Weight: 0.3 kg

Indirect Flow Measurement :

• Flow is calculated from the pump speed rather than measured directly
• The calculated flow rate can be displayed directly by the module
• Analog pump-speed output can be used for continuous recording of flow-related data

Included Accessories :

• Operating instructions
• Screwdriver
• Output cable to pump
• Connection cable for a compatible peristaltic pump

• control of peristaltic pump speed
• Supports constant-pressure perfusion
• Supports constant-flow perfusion
• Simple switching between constant-pressure and constant-flow operation
• Calculates perfusion flow from pump speed
• Provides indirect flow measurement
• Digital indication of actual value, setpoint or control output signal
• Analog output of 0 to 10 V corresponding to pump speed
• Suitable for continuous flow recording using a computer-based data acquisition system
• Adjustable control gain
• Adjustable derivative factor
• Adjustable integral factor
• Closed-loop pressure control
• Designed for physiological and pharmacological research
