Sound Cubicle Double Door Peep for Physiological Research Instrumentation

The Sound Cubicle – Double Door Peep provides a controlled environment with reduced sound and light intrusion for physiological and behavioral research applications. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Designed for controlled animal research environments
• Suitable for front-loading and top-loading test chambers
• Provides reduced light and sound intrusion while allowing convenient animal access

Construction :

• Moderately expanded PVC foam panels
• Resistant to moisture and many chemicals
• Outside wall thickness: 0.75 in (19 mm)
• Internal metal offset baffles help reduce wasted space

Double-door design :

• Double doors with rubber sealing to minimize air and light intrusion
• Larger left door allows animals to be loaded through a single door
• Covered peephole for animal observation
• Door hinges allow 180° movement
• Doors can be removed quickly without tools when required

Sound and light control :

• Offset design for exhaust fan, air inlet and cable porthole helps reduce sound loss and light intrusion
• Rated attenuation: -30 dB
• Measured attenuation: -25 dB with white noise at 3 ft distance

Slide-out tray :

• Standard slide-out tray
• Suitable for front-loading and top-loading chambers

Tray dimensions :

• 25.4 W x 17.4 D in
• 64.5 x 44.2 cm

Ventilation :

• 24 V ventilation fan
• Maximum airflow: 36 cu ft/min

House light :

• 28 V: 1.6 MSCP with 1000-hour life
• 24 V: Slightly reduced brightness with increased service life

Outer dimensions :

• 30.5 L x 19.75 D x 19.6 H in
• 77.47 x 50.17 x 49.8 cm

Weight :

• Approximately 55 lbs (24.95 kg)

Single door weight :

• 10 lbs (4.54 kg)
