Sterile Single Use Wide Range Pressure Sensors for Physiology Lab

Small-scale in-line sterile pressure sensors suitable for a variety of applications, including in vivo, ex vivo, in situ and regenerative organ and cellular applications. The sensors support different connection configurations for dead-end, low-flow and non-in-line applications. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Accuracy :

• Better than ±2% of reading from 0 to 6 psi (0 to 0.41 bar or 0 to 310 mmHg)
• Better than ±3% of reading from 6 to 30 psi (0.41 to 2.07 bar)
• Typically better than ±5% of reading from 30 to 60 psi (2.07 to 4.14 bar)

Pressure Range :

• -7 to +75 psi (-0.48 to +5.2 bar)

Biocompatibility :

• All materials in contact with the product fluid path meet USP Class VI requirements

Manufacturing Environment :

• FDA Registered ISO 13485-certified facility
• Class 100,000 clean room

Gamma Irradiation :

• Up to 50 kGy

Operating Temperature :

• 15 to 40°C
• Other ranges available with process qualification

Storage Temperature :

• -25° to 65°C

Input/Output Impedance :

• 270 to 4,000 Ω

Excitation Voltage :

• 2.5 to 10 VDC

Sensor Output :

• 0.2584 mV/psi/Volt

Connector :

• Custom molded water-tight 4-pin connector
• Signal ± and excitation ±

Additional Equipment :

• Manual pressure calibrator
• Pressure calibration range: 0 to 300 mmHg

• Small-scale in-line sterile pressure sensors
• Suitable for in vivo, ex vivo, in situ and regenerative organ and cellular applications
• Male/Female Luer lock with port cover for the female Luer lock end
• Suitable for dead-end applications
• In-line pressure measurement for low flow rates
• Compatible with 1/8-in or 1/16-in barbed connectors
• Can be paired with adapter Tee-connectors
• Compatible with 1/4-in or 3/8-in barbed connectors for non-in-line applications
