Stimulator CS for Isolated Cells for Physiology Lab

The Stimulator for Isolated Cells is an electronic square wave stimulator specially designed for electrical field stimulation of isolated cells such as myocytes. It can also be used for other stimulation applications where high currents are required. The stimulator provides constant-voltage monophasic, biphasic, or alternating stimulation with output currents greater than 1 A. Biphasic stimulation with symmetrical pulses helps reduce electrochemical effects such as electrode polarization and gas bubble formation. Short and powerful impulses can be used to activate action potentials while minimizing further influence of the stimulus on cell reactions. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Electrical stimulation of isolated cells
• Myocyte stimulation
• Electrical field stimulation
• Determination of cell reaction threshold voltage
• Other stimulation applications requiring high currents

Stimulation Modes :

• Monophasic
• Biphasic
• Alternating

Stimulation Current :

• Greater than 1 A

Stimulus Output Voltage :

• Adjustable from 0 to 45 V

Output :

• Floating and not connected to earth (ungrounded)
• Very low impedance: less than 1 Ohm

Display :

• LCD display for stimulation mode and timing
• Built-in digital voltmeter for stimulus output voltage

Timing Control :

• Timing settings adjusted using the Menu button and adjustment knob
• Last timing setting stored in backup memory
• Stored timing setting recalled automatically after switching on the instrument

Amplitude Control :

• Stimulus output voltage adjusted
• Two potentiometers provide adjustment from 0 to 45 V

Current Limiting :

• Dynamic current limiter built into the output circuit
• Maximum output current is limited relative to stimulation width
• Helps prevent overheating of the output circuit

Available Power Supply Versions :

• 115 VAC, 60 Hz
• 220 VAC, 50 Hz

• Easy to use
• Specially designed for isolated cell stimulation
• Suitable for electrical field stimulation of isolated cells
• Suitable for myocyte stimulation
• Constant-voltage monophasic stimulation
• Constant-voltage biphasic stimulation
• Constant-voltage alternating stimulation
• Output current greater than 1 A
• High output impulse current
• Short and powerful stimulation impulses
• Backup memory for timing settings
• LCD display for stimulation mode and timing
• Built-in digital voltmeter for stimulus output voltage
• Floating, ungrounded output
• Very low output impedance of less than 1 Ohm
• Built-in dynamic current limiter to prevent overheating of the output circuit
