Tall Sound Cubicle Double Door Peep for Physiological Research Instrumentation

The Tall Sound Cubicle – Double Door Peep is designed to provide a controlled environment with reduced sound and light intrusion for physiological and behavioral research. Manufactured by Atico Export with attention to applicable quality, safety and functional requirements for physiological research and laboratory applications.

• Designed for controlled animal research environments
• Suitable for front-loading and top-loading test chambers
• Provides reduced light and sound intrusion while allowing convenient animal access

Construction :

• Moderately expanded PVC foam panel construction
• Resistant to moisture and many chemicals
• Outside wall thickness: 0.75 in (19 mm)
• Internal metal offset baffles help reduce overall dimensions and minimize unused space

Double-door design :

• Double doors with rubber sealing to reduce air, light and sound intrusion
• Left door is larger than the right door for convenient single-door animal loading
• Covered peephole for animal observation
• Door hinges allow 180° movement
• Doors can be quickly removed without tools when required

Sound and light control :

• Offset design for exhaust fan, air inlet and cable porthole helps minimize sound loss
• Design also reduces light intrusion associated with straight-access cubicles
• Rubber door seals support improved environmental isolation

Slide-out tray :

• Standard slide-out tray
• Suitable for both front-loading and top-loading chambers
• Tray dimensions: 25.4 in L x 17.4 in D

Ventilation :

• 28 V DC ventilation fan included
• Integrated ventilation system supports controlled internal conditions

House light :

• Integrated house light included

Power requirements :

• 24 to 28 V DC
• 125 mA

Weight :

• 75 lbs

Outer dimensions :

Length :

• 30.5 in

Depth :

• 19.75 in

Height :

• 29.6 in

Inner dimensions :

Length :

• 29.0 in

Depth :

• 18.06 in

Height :

• 27.0 in
