Thermal Gradient test for Behavioral Research test

The Thermal Gradient Test System is designed for thermal nociception studies in freely moving rodents such as mice and rats. A continuous temperature gradient is established over a 120 cm long base plate, allowing the animal to move freely and select its preferred temperature zone. The system provides an automated approach for analgesia and nociception research, particularly studies involving thermal sensitivity and allodynia. The stable temperature gradient across the surface and over time allows accurate identification of the animal's preferred temperature zone. Integrated software and video monitoring enable analysis of the time spent by each animal in different temperature zones and the overall distance travelled. Video and encrypted experimental data are recorded synchronously in real time, supporting behavioral review and GLP-compliant research workflows. Manufactured by Atico Export with a focus on reliable performance for animal behavioral and nociception research.

• Thermal nociception studies
• Analgesia research
• Allodynia research
• Thermal sensitivity assessment
• Animal behavioral research
• Temperature preference studies
• Preclinical pain research

Temperature Gradient :

• -4°C to 65°C

Base Plate Length :

• 120 cm

Animal Compatibility :

• Mice
• Rats

Testing Capacity :

• Up to 2 mice or small rats simultaneously
• 1 adult rat

Measured Parameters :

• Time spent in each temperature zone
• Preferred temperature zone
• Overall travelled distance
• Animal behavioral responses during thermal nociception testing

Video & Data Recording :

• Video camera integration
• Synchronized video and experimental data recording
• Real-time recording
• Encrypted data
• Remote replay and behavioral review

Upgrade Option :

• Accessory kit available to upgrade the system to a two thermal choice test

• Operator-independent thermal nociception testing
• Suitable for freely moving rodents
• Continuous thermal gradient over a 120 cm base plate
• Stable temperature gradient across the surface
• Stable temperature gradient over time
• Automated temperature preference assessment
• Suitable for analgesia and nociception research
• Particularly suitable for allodynia research
• Simultaneous testing capability
• Integrated video monitoring
• Synchronized recording of video and experimental data
• Encrypted experimental data
• Remote behavioral review capability
• Supports GLP-compliant research
