Thermocouple Amplifier Module for Physiology Lab

hermocouple amplifier module designed for accurate temperature measurement using thermocouple probes. It supports thermocouple probes in a wide range of forms and dimensions, from thin wires with a diameter of 0.23 mm to larger probes with a diameter of 4 mm. The temperature probes are directly interchangeable and do not require individual calibration. The module provides a measurement range of 0°C to 100°C, with basic accuracy of 0.1°C in the physiological temperature range of 30°C to 45°C and 0.2°C outside this range. A built-in digital display provides 0.1°C resolution. The module also provides an analog output for connection to a recorder or data acquisition system and includes a built-in two-point calibration facility. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Thermocouple Probe Compatibility :

• Type T thermocouple probes
• Copper-constantan thermocouples
• Probe diameters ranging from approximately 0.23 mm to 4 mm
• Various probe forms and dimensions available

Technical Specifications :

• Temperature range: 0°C to 100°C
• Resolution: 0.1°C
• Sensitivity in physiological range: 0.1°C between 30°C and 45°C
• Sensitivity outside physiological range: 0.2°C
• Response time: 0.2 seconds at 90% span
• Display: 3-1/2 digit LED display
• Analog output: For simultaneous recording through BNC connector on front panel
• Calibration: Two-point calibration with two freely selectable temperatures
• Connector: DIN 41612, 64-pin VG
• Input: Floating differential input
• Maximum isolation: 1500 Vrms
• Transient protection: ANSI/IEEE C37.90.1-1989
• Input protection: 240 VAC continuous
• Input connector: Thermoelement connector, blue
• Module width: 2-slot unit

Calibration & Recording :

• Built-in simulation device provides two adjustable temperature values for calibration
• Recorder or data acquisition system can be calibrated using the two-point calibration function
• Zero suppression allows temperatures within a limited range, such as 36°C to 38°C, to be recorded at high resolution

• Accurate temperature measurement using thermocouple probes
• Suitable for measuring temperature on small structures
• Compatible with thermocouple probes of different forms and dimensions
• Directly interchangeable temperature probes
• No individual probe calibration required
• Measurement range from 0°C to 100°C
• Basic accuracy of 0.1°C between 30°C and 45°C
• Accuracy of 0.2°C outside the 30°C to 45°C range
• Built-in digital display with 0.1°C resolution
• Analog output for connection to a recorder or data acquisition system
• Built-in temperature simulation device for calibration
• Two freely selectable calibration temperatures
• Zero suppression facility for recording a limited temperature range at high resolution
