Touchscreen Treadmill for Behavioral Research test

The Touchscreen Treadmill is designed for forced exercise training and accurate assessment of fatigue in small laboratory animals. The system features an adjustable rolling belt with controllable speed and positive or negative slope, allowing flexible exercise protocols for mice, rats, and rabbits. An integrated touchscreen control unit provides convenient control of belt speed, slope, and stimulus intensity while displaying experimental parameters including distance covered, accumulated shock time, and shock intensity. The treadmill uses constant-intensity electrical stimulation as a motivating stimulus, with an optional air-puff system available as an alternative. Convertible configurations allow selected rat and mouse treadmills to be adapted between species using interchangeable lids and grids. Optional computer connectivity supports data storage and user-defined exercise protocols, while specialized configurations are available for indirect calorimetry and respiratory metabolism studies. Manufactured by Atico Export with a focus on reliable performance for animal exercise, fatigue, metabolism, and behavioral research.

• Forced exercise training
• Fatigue testing
• Exercise physiology studies
• Motor coordination studies
• Locomotor performance research
• Respiratory metabolism studies
• Indirect calorimetry
• Animal behavioral research
• Exercise endurance assessment

Belt Speed Range :

• 0.4 to 150 cm/s for standard mouse and rat configurations
• 10 to 80 cm/s for rabbit configuration

Belt Slope :

• -25° to +25°

Electrical Shock Intensity :

• 0 to 2 mA
• Constant intensity

Stimulus Options :

• Electrical shock
• Optional air-puff stimulation

Control Interface :

• Integrated touchscreen graphical user interface

Control Unit Dimensions :

• 23 × 29.5 × 11 cm

Single Rat Exercise Area :

• 53 × 10 × 15 cm

Single Mouse Exercise Area :

• 38 × 5 × 5 cm

Rabbit Exercise Area :

• 73 × 30 × 31 cm

Two Rat Configuration :

• 2 × (53 × 10 × 15 cm)

Two Mouse Configuration :

• 2 × (38 × 5 × 5 cm)

Five Rat Configuration :

• 5 × (53 × 10 × 15 cm)

Five Mouse Configuration :

• 5 × (38 × 5 × 5 cm)

Data Parameters :

• Belt speed
• Belt slope
• Distance covered
• Accumulated shock time
• Shock intensity

Computer Communication :

• USB communication available through optional software

Protocol Control :

• Acceleration
• Deceleration
• Customized speed protocols
• User-defined stopping parameters

Animal Configurations :

• Single mouse
• Two mice
• Five mice
• Single rat
• Two rats
• Five rats
• Single rabbit

Convertible Configurations :

• Rat-to-mouse conversion
• Mouse-to-rat conversion using interchangeable lids and grids

Indirect Calorimetry Option :

• Available for respiratory metabolism studies

Maintenance :

• Minimal maintenance
• Easy cleaning

• Forced exercise training for laboratory animals
• Accurate fatigue testing
• Integrated touchscreen graphical user interface
• Adjustable belt speed from 0.4 to 150 cm/s
• Positive and negative belt slope from -25° to +25°
• Low-speed function for extended experimental flexibility
• Single- to five-lane configurations for mice and rats
• Single-lane configuration available for rabbits
• Convertible rat/mouse configurations
• Constant electrical shock intensity
• Shock intensity adjustable from 0 to 2 mA
• Optional air-puff stimulation as an alternative motivating stimulus
• Individual lane stimulation and control
• Parameters displayed on the control unit
• Records belt speed, slope, distance covered, accumulated shock time, and shock intensity
• Optional computer communication for data storage
• Supports user-defined acceleration, deceleration, and customized protocols
• Manual or automatic session stopping
• Models available for indirect calorimetry and respiratory metabolism studies
• Minimal maintenance required
• Easy cleaning
