Transducer Amplifier for Physiology Lab

High-gain differential AC/DC amplifier designed to work with a wide range of transducers for evaluating pressure, strength and respiration in various research applications, including experiments involving isolated organs and tissues. The amplifier includes a filter for suppressing background noise and electrical or mechanical artifacts that may affect signals from biological preparations. A transducer balance function allows fine adjustment of the signal baseline, while the external output monitoring facility enables connection to recording or display equipment such as an oscilloscope. The amplifier can operate in both AC and DC modes and provides signal amplification up to 2,000 times. The amplifier module requires a dedicated power supply box. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Pressure measurement
• Strength measurement
• Respiration measurement
• Isometric tissue preparation studies
• Isotonic tissue preparation studies
• Isolated organ research
• Organ bath experiments
• Physiological and pharmacological research

Gain :

• 0 to 2000

Input Impedance :

• 1.5 kΩ

Output Impedance :

• <100 Ω

Feed Power :

• 18 VDC

Output Voltage :

• 10 V

Transducer Power Supply :

• 10 VDC

Band Frequency :

• 0 to 5 kHz

Filters :

• 3 Hz or >20 Hz

AC Filter :

• 0.16 Hz

Connector :

• 5-pin female audio connector

Certification :

• CEE compliant

Power Supply Requirement :

• Requires a dedicated power supply box
• Power supply box can support up to four amplifier modules

• High-gain differential AC/DC amplifier
• Compatible with a wide range of transducers
• Suitable for pressure, strength and respiration measurements
• Amplification up to 2,000 times
• Built-in filter for suppression of background noise
• Helps reduce electrical and mechanical artifacts
• Transducer balance function for fine adjustment of signal baseline
• External output monitoring capability
• Suitable for isolated organ and tissue experiments
• Supports AC and DC operation
