Treadmill for Behavioral Research test

Treadmill System is a complete solution for assessing respiratory metabolism during treadmill-based exercise studies using indirect calorimetry. The system combines a rolling treadmill belt with adjustable speed and positive or negative slope, a touchscreen control unit, an air-isolated enclosure, airflow control, and gas analysis for measuring oxygen consumption and carbon dioxide production. The treadmill supports forced exercise training in rodents while providing controlled exercise intensity and accurate metabolic measurements. The rolling belt is designed for intensive use with minimal maintenance and easy cleaning, while the sufficiently wide exercise area allows animals to correct coordination errors for accurate fatigue assessment. Manufactured by Atico Export with a focus on reliable performance for animal exercise, metabolic, and physiological research.

• Respiratory metabolism studies
• Forced exercise training
• Treadmill exercise studies
• Indirect calorimetry
• Oxygen consumption assessment
• Carbon dioxide production assessment
• VOmax determination
• Fatigue assessment
• Exercise physiology research
• Rodent metabolic research

Treadmill Speed :

• Up to 150 cm/s
• Mouse configuration: 5 to 150 cm/s
• 2 to 59 in/s

Slope Range :

• -25° to +25°
• Positive and negative slope adjustment

Exercise Area :

• 38 × 5 × 5 cm
• 15 × 2 × 2 in

Subjects :

• One mouse for the specified configuration

Electrical Shock :

• Constant intensity
• Adjustable from 0 to 2 mA
• Current effect depends on the selected mA value rather than animal body mass in contact with the bars or perspiration

Control Unit :

• Touchscreen display
• Controls treadmill belt speed
• Displays measured data
• Provides electrical shock to the grid

Metabolism Enclosure :

• Air-isolated enclosure
• Designed for respiratory metabolism measurements

Airflow Control :

• Fine regulation of airflow inside the treadmill
• Air supplied to the gas analyzer for O2 and CO2 concentration determination
• Air stabilized through an air reservoir before analysis

Data Transfer & Software :

• Transfers treadmill and gas analyzer data to a PC
• RS232/USB outputs
• Supports data storage and further analysis

Control Unit Dimensions :

• 23 × 29.5 × 11 cm
• 9 × 11.6 × 4.3 in

Treadmill Dimensions Without Lid :

• 44 × 15 × 23 cm
• 17 × 6 × 9 in

Supporting Base / Foot Surface :

• 22 × 13 cm
• 9 × 5 in

Available Options :

• Standard lid
• OxyletPro metabolism lid
• Air puff option

Calibration :

• Calibration tanks are not supplied with the system and must be purchased separately.

• Complete solution for treadmill-based respiratory metabolism studies
• Indirect calorimetry for metabolic assessment
• Touchscreen treadmill control unit
• Adjustable belt speed
• Adjustable positive and negative slope
• High-performance motor
• Silent operation, including at high operating speeds
• Minimal maintenance requirements
• Easy-to-clean treadmill construction
• Controlled electrical shock intensity
• Air-isolated enclosure for metabolism studies
• Fine airflow regulation
• O2 and CO2 gas concentration analysis
• Data transfer to a PC for storage and analysis
• Suitable for rodent forced exercise studies
