Ultrasonic Aerosol Nebulizer System for Physiology Lab

Ultrasonic aerosol nebulizer system designed to produce high-quality aerosol without altering the formulation's molecular integrity. The system provides precise particle sizes of 2.5 to 4 µm, low flow rate and low residual volume. The nebulized substance does not contaminate the inspiration path of the ventilator. Suitable for rats, guinea pigs and rabbits. The low dead volume adapter maintains system compliance at 1.5 ml. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Aerosol delivery studies in rats
• Aerosol delivery studies in guinea pigs
• Aerosol delivery studies in rabbits
• Respiratory and physiological research
• Experimental aerosol administration using liquid formulations

Included Components :

• Ultrasonic aerosol nebulizer unit
• Filler cap
• Control and timing unit
• Power supply
• Low dead volume adapter

Ultrasonic Nebulizer :

• High-quality aerosol generation
• Volume median diameter: 2.5 to 4 µm
• Low-velocity aerosol
• Flow rate: approximately 0.1 ml/min
• Residual volume: less than 0.2 ml
• Preserves formulation molecular integrity
• Suitable for a broad range of liquid formulations
• Does not increase formulation concentration

Low Dead Volume Adapter :

• Effective dead volume: 1.5 ml
• Connection ports: 6 mm OD, 5 mm ID

System Performance :

• Maximum temperature after 15 minutes of use: 30°C
• System compliance with low dead volume adapter: 1.5 ml

• High-quality aerosol with precise particle size of 2.5 to 4 µm
• Low flow rate of approximately 0.1 ml/min
• Low residual volume of less than 0.2 ml
• Does not alter the formulation's molecular integrity
• Nebulized substance does not contaminate the inspiration path of the ventilator
• Suitable for rats, guinea pigs and rabbits
• Low dead volume adapter maintains system compliance at 1.5 ml
• System temperature does not exceed 30°C after 15 minutes of use
• Low-velocity aerosol generation
• Aerosolizes a broad range of liquid formulations without increasing concentration
