Vertical Tissue Bath System for Physiology Lab

Advanced tissue bath system designed for studying force or displacement from a wide variety of tissue preparations, including atria, papillary muscle without potential recording, skeletal muscle and smooth muscle such as intestine, bladder and uterus. The system can also be used for isolated intact blood vessel and nerve-muscle preparation experiments with suitable specialized holders. Available in single or four-channel configurations with multiple tissue vessel volumes, tissue holders, force and displacement transducers, stimulation options and data acquisition capabilities. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Smooth muscle studies
• Heart muscle studies
• Skeletal muscle studies
• Ring and strip preparations
• Atria preparations
• Papillary muscle studies without potential recording
• Intestine studies
• Bladder studies
• Uterus studies
• Isolated intact blood vessel experiments
• Nerve-muscle preparation experiments

Design :

• Rigid and ergonomic construction for rapid tissue mounting
• Tissue bath volumes available in 5, 10, 20 and 50 ml
• Bath-specific and tissue-specific holder options
• Tissue supports available for rings, strips and specialty applications
• Tissue holders available with or without platinum plate field stimulation electrodes
• Integrated oxygenating frit at the rear of each tissue holder
• Force and displacement transducers mounted on Vernier positioners
• Vernier micropositioner allows precise preload or pre-stretch adjustment for force transducers
• Vernier micropositioner allows suitable zero adjustment within the range of displacement transducers

Set Up & Operation :

• Integrated platform carries the tissue holder, micropositioner and transducer
• Platform can be raised to bring the tissue holder out of the glass vessel for easy tissue access
• Flushing solution is warmed using flow-through heat exchangers
• Central connection provided for gas addition
• Six needle valves provide individual gas-flow adjustment
• Gas flow can be individually adjusted for four tissue vessels, preparation dish and solution reservoir
• Electrical stimulation requires suitable tissue holders with stimulation electrodes
• Suitable stimulator should provide separate outputs for each tissue
• Stimulator should provide stimulus trains suitable for smooth muscle stimulation
• Stimulus amplitude should be individually adjustable for each tissue

System Components :

• Tissue preparation dishes
• Buffer reservoirs
• Tissue supports
• Force transducers
• Displacement transducers
• Transducer amplifiers
• Multi-channel stimulators
• Stand-alone or programmable stimulators
• Thermocirculator
• Required tubing and connectors

Additional Equipment Required :

• Thermocirculator
• Solution reservoir
• Suitable force or displacement transducers
• Monitoring system
• Amplifier system for force and displacement measurements
• Data acquisition software for recording and exporting measurements
• Optional hardware and software modules for computer-controlled field stimulation
• Optional electronically controlled Vernier positioners for tissue pretension
• Optional hardware and software for tissue bath flushing
• Multiple-output stimulator for electrical stimulation

• Single or four-channel tissue bath configurations
• Tissue vessel volumes of 5, 10, 20 and 50 ml
• Multiple tissue holder options for different applications
• Software for data acquisition and control
• Two flushing modes: overflow and drain/refill
• Wide range of force and displacement transducers
• Rigid construction and ergonomic design
• Rapid tissue mounting and adjustment
• Integrated oxygenating frit to minimize disruption caused by bath oxygenation
• Precise preload and zero adjustment using micropositioners
• Suitable for tissue-specific supports and stimulation applications
