Vogel Test Home cage for Behavioral Research test

The Vogel Test Home Cage is a complete home cage system designed for conducting the Vogel conflict test as a standard method for fast screening of the potential anxiolytic properties of drugs. The system allows Vogel experiments to be performed directly in the animal's home cage. A specially designed nipple and electronic detection system detect and count licking responses while excluding non-specific contacts. Different cage configurations are available for mice and rats, and the system can be configured for simultaneous testing of up to 32 cages with computer-based protocol control, data acquisition and analysis. The system is manufactured by Atico Export for reliable performance in animal behavioral and pharmacological research.

• Vogel conflict test
• Fast screening of potential anxiolytic properties of drugs
• Animal behavioral research
• Drinking behavior studies
• Pharmacological research
• Drug screening studies

Cage Configuration :

• Different cage configurations available for mice and rats
• Mouse cage also suitable for small rats below 300 g
• Large rat cage configuration available

Multi-Cage Capacity :

• Up to 32 cages can be operated simultaneously
• Each cage is associated with one lick sensor/shock generator
• Up to 8 lick sensor/shock generators can be connected to one link box
• Up to 8 link boxes can be connected in a daisy-chain configuration

Lick Detection :

• Special nipple system detects and counts licking responses
• Designed to exclude casual and non-specific contacts from drinking responses

Shock Duration :

• 0.1 to 10 seconds

Shock Range :

• 0.1 to 2 mA

Computer Communication :

• RS232/USB communication

Software Function :

• Protocol edition
• Data acquisition
• Data analysis
• Vogel test protocol and data reporting functions

System Components :

• Home cage with nipple, bottle and electric contacts for nozzle and grid
• Lick detector and shock generator
• Link box for multi-cage configuration
• Computer communication interface
• Vogel test experimental module
• Spare nipple and bottle
• Electric contacts for nozzle and grid

• Allows Vogel experiments directly in the animal's home cage
• Exclusive nipple system helps exclude non-specific contacts
• Different cage configurations available for rats and mice
• Supports simultaneous testing of up to 32 cages
• Computer-based protocol editing, data acquisition and data analysis
• Compatible with laptop use
• Each home cage can be associated with a lick sensor and shock generator
• Multi-cage configuration supports connection through link boxes
• RS232/USB communication for computer connectivity
