Wire Myographs for Physiological Research Instrumentation

The Wire Myograph system is designed for ex vivo investigation of microvessel contractility, vascular reactivity and functional responses following pharmacological challenges. It supports studies on small arteries, veins, lymph vessels and tracheal smooth muscles, with configurations for multiple baths and controlled temperature conditions. Manufactured by Atico Export with attention to applicable quality, safety and functional requirements for physiological research and laboratory applications.

• Designed for investigating functional responses and vascular reactivity of small arteries, veins, lymph vessels and tracheal smooth muscles
• Suitable for ex vivo preclinical research
• Used to examine microvessel contractility following drug challenges
• Commonly used in drug development and toxicology studies
• Supports investigation of vessel responses to agonists or antagonists added to the bath
• Generates Concentration Response Curves (CRC)
• Suitable for vascular biology and heart failure and cardiac model development studies

Techniques & Measurements :

• Wire myography
• Microvessel contractility assessment
• Vascular reactivity measurement
• Concentration Response Curve (CRC) generation

Compatible Software :

• Data acquisition software
• Data reduction software

Configurations :

• Maximum number of baths: 2
• Bath volume: 5 ml
• Microvessel size: Diameter 100 µm–3 mm; length up to 3.5 mm
• Individual temperature control by bath
• No in-line physiological liquid heating; water bath required
• Bath temperature range: 20.0–39.0 °C ± 0.1 °C (68–102.2 °F ± 0.18 °F)
• Frame size: 300 × 335 × 206 mm
• Weight: 2 kg
• Bubbling: Frit glass
• Analog output: 0–5 V
• Connection: USB or analog
• Maximum number of baths: 4
• Bath volume: 5 ml
• Microvessel size: Diameter 100 µm–3 mm; length up to 3.5 mm
• Same temperature for all baths
• In-line heating of physiological liquid before entering the bath
• Bath temperature range: 20.0–39.0 °C ± 0.1 °C (68–102.2 °F ± 0.18 °F)
• Frame size: 641 × 500 × 345 mm
• Weight: 18 kg
• Bubbling: Frit glass
• Analog output: 0–5 V
• Connection: USB or analog

• Modular
• Easy to use
• Reproducible
• Suitable for different experimental configurations
• Supports small vessel and tissue studies
