Mechanical Grease Worker for Oil and Petroleum Testing Equipment

The Mechanical Grease Worker is designed to perform worked penetration and prolonged worked penetration tests to determine the consistency of lubricating greases. The instrument consists of a steel grease worker mounted on a sturdy base and driven by a gear reduction motor. It operates according to the required stroke length and rate for standardized grease testing.

An electronic preset counter automatically stops the drive motor after the selected number of strokes, up to 99,999. The steel grease worker includes a threaded cup and cover, a plunger plate with shaft and handle, and a vent cock for temperature measurement. Spring-loaded clamps secure the grease worker during operation, while built-in pins facilitate disassembly after testing.

Manufactured by Atico Export for dependable grease consistency testing and quality control in petroleum laboratories.

• Worked penetration testing of lubricating greases
• Prolonged worked penetration testing
• Determination of grease consistency
• Quality control and evaluation of lubricating grease performance

Drive Motor :

• Single-unit model: 1/3 hp
• Double-unit model: 1/2 hp
• Fan-cooled gear reduction type

Power Supply :

• 115 V, 60 Hz, single phase, 3 A
• 220–240 V, 50/60 Hz, single phase, 1.5 A

Dimensions – Single-Unit Model (L × W × H) :

• 25 × 34 × 37 cm (10 × 13½ × 14¾ inches)

Dimensions – Double-Unit Model (L × W × H) :

• 36 × 34 × 37 cm (14 × 13½ × 14¾ inches)

Net Weight :

• Single-unit model: 45.4 kg (100 lbs)
• Double-unit model: 63.1 kg (139 lbs)

Shipping Weight :

• Single-unit model: 72.2 kg (159 lbs)
• Double-unit model: 87.6 kg (193 lbs)

Shipping Dimensions (Mechanical Models) :

• 61 × 53.4 × 55.9 cm (24 × 21 × 22 inches)

Available Accessories :

• Dial thermometer with adapter for insertion into the grease worker vent cock
• Overflow ring for collecting displaced grease during penetration measurements
• Steel grease worker complete with cup, cover, plunger, and vent cock
• Steel grease worker with 270-hole plunger plate for applicable test procedures
• Replacement cover assembly with vent cock, plunger plate, shaft, and handle
• Grease cup
• Blank lid with seal for covering the grease worker during sample heating

• Mechanical and manually operated configurations
• Available in single-unit and double-unit models
• Powerful fan-cooled gear reduction motor
• Electronic preset stroke counter with automatic motor shut-off
• Stroke count programmable up to 99,999
• Steel grease worker with threaded cup and cover
• Plunger plate with shaft and handle
• Vent cock for thermometer insertion
• Spring-loaded clamps for secure mounting
• Base pins for convenient disassembly after testing
