Automatic analyzer for salt content in petroleum and bitumen ASTM D3230 for developing and manufacturing laboratory test equipment

The automatic salt analyzer is designed to determine salt concentration in petroleum products and bitumen. It delivers measurements in less than 30 seconds, automatically displays salt concentration values, and selects the appropriate testing tables based on sample temperature. Manufactured by Atico Export with quality-focused production and attention to engineering specifications for oil, fuel and petroleum product analysis.

Operating Mode :

• Automatic operation
• Measurement time: Less than 30 seconds
• Automatic display of salt concentration values
• Automatic selection of testing tables

Temperature Measurement :

• Range: 0C to 50C
• Temperature units: C or F

Measurement Features :

• Salt concentration results displayed in PTB, g/m and mg/kg
• Automatic measurement range adjustment
• Automatic voltage adjustment
• Test voltage: Up to 250 V
• Measurement accuracy: 1 V / 0.01 mA
• Interchangeable sensor
• User calibration modes for verification against reference standards
• Preset calibration at 3 different temperatures
• Language options: French and English

Supplied With :

• Cover with electrodes
• Beakers with rings

Options and Accessories :

• Calibration for IP method
• Specific temperature calibration
• Calibration for salt determination in bitumen at 20C
• Thermal ticket printer
• Carrying case
• Calibration kit
• Paper roll

Safety Features :

• Protective safety cover for the operator
• Short-circuit prevention
• Hall-effect sensor for power cutoff when the cover is open
• Audible alarm during measurement
• Indicator light

Power Supply :

• 115 V / 230 V, 50/60 Hz, 1 A
• Supported supply range: 100240 V

Dimensions :

• Width: 250 mm
• Depth: 380 mm
• Height: 290 mm

Weight :

• 7 kg
