Automatic flash point - Pensky Martens ASTM D8175 and ASTM D93 for developing and manufacturing laboratory test equipment

The automatic flash point tester is designed for determining the flash point of petroleum products under controlled laboratory conditions. It features a temperature range of 0C to 410C, three predefined testing methods, user-programmable methods, automatic gas flame relighting, and rapid cooling through an integrated forced-air system. Manufactured by Atico Export for reliable performance in demanding oil-field, fuel testing and petroleum research applications.

Temperature Range :

• 0C to 410C

Heating System :

• Heating rate: 0 to 15C/min
• Electric and gas ignition
• Automatic gas flame relighting
• Automatic stirring start during heavy sample preheating

Testing Methods :

• Method A
• Method B
• Method C
• User-programmable methods

Cooling System :

• Rapid cooling of the heating block using an air turbine
• Integrated forced-air cooling

Detection System :

• Flash point detection using thermocouple
• Gas flame detection through ionization

Supplied With :

• Cup and lid
• PT100 probe
• Detection thermocouple
• Electric ignitor

Options and Accessories :

• Ticket printer
• Automatic nitrogen fire extinguisher

Safety Features :

• Illuminated extinguisher activation button
• Gas flame detection
• Overtemperature protection
• Built-in gas leak detector
• Manual extinguisher activation and automatic shutdown through the nitrogen supply system

Software and Data Management :

• User-friendly interface
• Windows 8 operating system
• 32 GB SSD for long-term data storage
• Report export in PDF, Excel, Word, email and LIMS formats
• Configurable access levels for operators, supervisors and maintenance personnel

Gas Connections :

• Propane or butane
• Nitrogen

Power Supply :

• AC 110 - 240 V, 50/60 Hz, 4 A

Dimensions :

• Width: 260 mm
• Depth: 460 mm
• Height: 185 mm

Weight :

• 12 kg
