Automatic Saybolt and ASTM Colorimeter for Oil and Petroleum Testing Equipment

The Automatic Petroleum Product Color Analyzer is a high-precision spectrophotometer designed for objective color measurement of petroleum fuels, mineral oils, waxes, and petrochemical products using the Saybolt and ASTM Color scales.

The instrument is suitable for visual color assessment of lubricating oils, heating oils, diesel fuels, petroleum waxes, refined oils, undyed motor and aviation gasoline, jet fuels, naphthas, kerosene, and pharmaceutical white oils. Its optical measurement system uses 16 interference filters across a spectral range of 420–710 nm to provide repeatable color analysis. The long optical path length supports accurate Saybolt Color measurements of clear, water-white products.

Manufactured by Atico Export for reliable color analysis and quality control in petroleum testing laboratories.

• Color measurement of diesel fuels and petroleum waxes
• Saybolt Color determination of refined oils and clear petroleum products
• Testing of gasoline, aviation fuels, jet fuels, naphthas, and kerosene
• Color analysis of mineral oils and petrochemical products

Measuring Principle :

• 16 interference filters

Spectral Response :

• 420–710 nm

Bandwidth :

• 20 nm

Repeatability :

• Chromaticity (x, y): ±0.0002
• Transmittance: ±0.25%
• Saybolt values: ±1

Measurement Time :

• Less than 25 seconds

Calibration :

• Fully automatic, single-key operation

Light Source :

• 5 V, 10 W tungsten-halogen lamp

Illuminant :

• CIE Illuminant C

Observer Angle :

• 2°

Optical Path Length :

• 0.1–153 mm

Display :

• Backlit LCD, 2 × 40 characters

Keypad :

• 21-key washable polyester membrane keypad with audible feedback

Interfaces :

• Parallel printer port
• RS232 port

Input Voltage :

• Universal input via external power supply

Optional Heater Unit :

• Maximum temperature: 95°C

Instrument Housing :

• Fabricated sheet steel with textured paint finish

Dimensions (W × D × H) :

• 51.5 × 19.5 × 17.0 cm (20¼ × 7¾ × 6¾ inches)

Net Weight :

• 7.75 kg (17.1 lbs)

Standard Accessories :

• 100 mm optical glass cell
• 33 mm optical glass cell
• Calibrated glass conformance filter
• Spare lamp
• Operation manual

• High-precision spectrophotometric color measurement
• Supports Saybolt and ASTM Color scales
• 16 interference filters for optical measurement
• Automatic calibration at the press of a key
• Measurement time of less than 25 seconds
• Backlit LCD display
• Washable membrane keypad with audible feedback
• Printer and RS232 communication interfaces
• Optional factory-fitted heater unit
• Multilingual operating instructions
