Automatic softening point - ball & ring method ASTM D36 and ASTM E28 for developing and manufacturing laboratory test equipment

The automatic softening point tester is designed to determine the softening point of bitumen and related materials using the ring and ball method. It supports simultaneous testing of two samples and features automatic optical detection, an 8.4-inch capacitive color display, and a temperature range up to 200C. Manufactured by Atico Export with precision, safety and practical testing requirements in mind for petroleum laboratory applications.

Temperature Range :

• Up to 200C

Operating Temperature :

• 5C to 30C

Testing Capacity :

• 2 samples simultaneously

Preset Methods :

• Water
• Glycerine
• Glycol
• Silicone oil

Supplied With :

• Beakers
• Shouldered rings
• Balls
• Holder
• Mechanical stirrer
• Magnetic stirrer
• Magnetic removal stick
• Magnetic ball dropper
• Centering guides
• Molding plate

Options and Accessories :

• Magnetic ball dropper
• Magnetic and mechanical stirrers
• Magnetic removal stick for magnetic stirrer
• Different types of rings
• Beakers for ASTM D36
• Molding plate
• Ball centering guide
• Printer
• ASTM E28 beaker with anti-condensation treatment

Safety Features :

• Multiple user access levels
• Sample overheating protection
• Audible and visual alarms
• Automatic shutdown if the probe is missing
• Waterproof heater
• Solvent-resistant display screen

Software and Data Management :

• Data updates and backups through USB
• Connectivity for keyboard, mouse, barcode reader and printer
• 320 GB hard drive storage
• Data export through USB, LIMS, PDF and email
• Customizable reports
• User-friendly software interface
• User and password management
• Data transfer to printer
• Configurable testing methods

Power Supply :

• 200 - 250 V, 50/60 Hz, 3.3 A

Dimensions :

• Width: 380 mm
• Depth: 290 mm
• Height: 580 mm

Weight :

• 14.8 kg

• Automatic optical detection system
• 8.4-inch capacitive color display
• Adjustable heating rate
• Adjustable stirring speed up to 250 rpm
• Automatic cooling by mechanical fan at the end of the test
• Temperature measurement using PT100 sensor
• Temperature units: C or F
