Determining the penetration value - manual ASTM D1321 , ASTM D1403 , ASTM D217 , ASTM D5 and ASTM D937 for developing and manufacturing laboratory test equipment

The semi-automatic penetrometer is designed for determining the penetration value of bitumen, waxes, lubricating greases and other petroleum products. It features four programmable positions, a precision stepper motor, optoelectronic penetration depth detection, and programmable penetration time. Manufactured by Atico Export with a focus on precision, durability and consistent performance in petroleum testing laboratories.

Operating Features :

• 4 operating speeds: 3 downward and 1 upward
• 4 programmable positions
• Precision stepper motor with an accuracy of 0.05 mm
• Programmable penetration time
• Optoelectronic detection of penetration depth
• Automatic surface detection available as an option
• Flexible LED lamp and magnifying glass

Supplied With :

• Flexible magnifying lens
• Flexible LED lamp
• Needle holder
• 1 power cable

Options and Accessories :

• Cryostat
• Transfer bath and support
• Cooling incubator
• Automatic approach kit for conductive products
• Automatic holder for hard bitumen
• Application-specific accessories kit available on request

Temperature Range :

• 10C to 150C

Temperature Unit :

• C or F

Penetration Range :

• 0 to 75 mm

Accuracy :

• 0.05 mm

Penetration Time :

• Programmable up to 999 minutes

Operating Humidity :

• 30% to 80% RH maximum

Safety and Indicators :

• Automatic detection
• Visual and audible overflow indicators

Software and Data Management :

• Integrated software
• Programmable operating mode, pause time, penetration time, penetration limit and other parameters
• Memory for 10 results
• Storage capacity of up to 20 tables

Power Supply :

• 240 V, 50�60 Hz, 1 A

Dimensions :

• Width: 250 mm
• Depth: 330 mm
• Height: 720 mm

Weight :

• 16 kg
