Foaming characteristics of lubricating oils ASTM D892 for developing and manufacturing laboratory test equipment

The lubricating oil foaming characteristics tester is designed to evaluate the foaming tendency and stability of lubricating oils under controlled temperature and airflow conditions. It features test baths operating at 24C and/or 93.5C, electronic temperature control with a digital display, and calibrated flowmeters for precise airflow adjustment. Manufactured by Atico Export to support reliable testing and quality control in petroleum and lubricant laboratories.

Temperature Control :

• Test bath temperatures: 24C and/or 93.5C
• Electronic temperature control with digital display
• Cooling coil for room-temperature testing and improved stabilization at 24C

Testing Capacity :

• 2 test positions per bath
• Integrated calibrated flowmeters for airflow adjustment and control
• 2 flowmeters per bath
• Color-coded quick connectors for input and output connections

Testing Methods :

• Foam 1: Sequences I and II
• Foam 2: Sequences I, II and III

Supplied With Foam 1 :

• Spherical diffusers
• Test tubes
• Flowmeters
• ASTM 12C thermometer
• Test baths for 24C and 93.5C

Supplied With Foam 2 :

• Test baths for 24C and 93.5C
• ASTM 12C thermometers
• Diffusers

Options and Accessories :

• Foaming sphere washer with integrated pump
• Hydraulic meter
• Cryostat cooling system
• Compressor for supplying air to flowmeters
• Gas drying column
• Cylindrical diffusers

Power Supply Foam 1 :

• 230 V, 50 Hz, 10 A

Dimensions Foam 1 :

• Width: 340 mm
• Depth: 340 mm
• Height: 770 mm

Weight Foam 1 :

• 20 kg

Power Supply Foam 2 :

• 230 V, 50 Hz, 10 A

DimensionsFoam 2 :

• Width: 880 mm
• Depth: 340 mm
• Height: 770 mm

Weight Foam 2 :

• 40 kg
