Foaming characteristics of lubricating oils at high temperatures ASTM D6082 and ASTM D892 for developing and manufacturing laboratory test equipment

The high-temperature lubricating oil foaming tester is designed to evaluate the foaming characteristics of lubricating oils under controlled temperature and airflow conditions. It features a high-performance dual-station configuration with operating temperatures of 24C, 93C and 150C, controlled by an electronic regulator. Manufactured by Atico Export for reliable performance in lubricant testing and petroleum research applications.

Testing Capacity :

• Dual-station configuration

Operating Temperatures :

• 24C
• 93C
• 150C

Control System :

• Electronic temperature regulator

Testing Methods :

• Supports Sequences I, II, III and IV of ASTM D892 and ASTM D6082

Supplied With :

• 1000 mL weighted test tubes with caps
• Calibrated flowmeters with needle valves
• Bath shaker
• Stainless steel diffusers
• ASTM 41C thermometer

Options and Accessories :

• Foaming sphere washer with integrated pump
• Hydraulic meter
• Cryostat cooling system
• Compressor for supplying air to flowmeters
• Gas drying column
• Polyalphaolefin bath oil

Safety Features :

• Protective glass enclosure

Power Supply :

• 230 V, 50 Hz, 10 A

Dimensions :

• Width: 750 mm
• Depth: 350 mm
• Height: 760 mm

Weight :

• 40 kg
