Loss on Heat Thin Film Oven for Oil and Petroleum Testing Equipment

The Asphalt Oven is designed to evaluate the effects of heating on bitumen and asphaltic materials under prescribed conditions. Testing results are determined by measuring changes in sample mass and selected properties, such as viscosity, penetration, and ductility, before and after the oven cycle.

The dual-purpose oven supports loss-on-heating and thin-film testing. It features a stainless steel interior chamber, a powder-coated steel exterior, and a double-glazed viewing window for monitoring samples during testing. The side-mounted control panel includes a microprocessor-based digital controller, an independent over-temperature thermostat, a main switch, and indicator lamps. Two rotating platforms are supplied to perform both test procedures.

Manufactured by Atico Export for reliable asphalt aging evaluation and quality control in bitumen testing laboratories.

• Loss-on-heating testing of bitumen and asphaltic materials
• Thin-film testing of asphalt samples
• Evaluation of changes in sample mass after heating
• Assessment of changes in viscosity, penetration, and ductility
• Quality control of bituminous materials

Temperature Range :

• Up to 180°C (356°F)

Preset Test Temperature :

• 163°C ±1°C

Power Supply :

• 110 V, 60 Hz
• 220 V, 50 Hz
• 220 V, 60 Hz

Internal Chamber Dimensions (H × W × D) :

• 38 × 52 × 46 cm

External Dimensions (H × W × D) :

• 57 × 87 × 63 cm
• External dimensions exclude the motor and handle

Net Weight :

• 68.5 kg (151 lbs)

• Dual-purpose oven for loss-on-heating and thin-film tests
• Stainless steel interior chamber
• Powder-coated steel exterior
• Double-glazed door window for sample observation
• Microprocessor-based digital temperature control
• Independent over-temperature thermostat
• Main power switch and indicator lamps
• Two rotating platforms supplied for the two test procedures
