Oil Solvent Extractables Content Apparatus for Oil and Petroleum Testing Equipment

The Petroleum Wax Oil Content Tester is designed to determine the oil content or solvent-extractable content in petroleum waxes. Oil content can affect important wax properties such as strength, hardness, and melting point.

The test sample is dissolved in methyl ethyl ketone or a 50:50 mixture of methyl ethyl ketone and toluene. The solution is cooled to precipitate the wax and then filtered. The oil content or solvent-extractable content of the filtrate is determined by evaporating the solvent and weighing the remaining residue.

Manufactured by Atico Export for reliable oil content determination and quality evaluation of petroleum waxes.

• Determination of oil content in petroleum waxes
• Measurement of solvent-extractable content
• Evaluation of wax properties, including hardness, strength, and melting point
• Quality control and laboratory testing of petroleum wax products

Filter Stick and Assembly :

• Sintered glass filter stick diameter: 10 mm
• Includes air pressure inlet tube and delivery nozzle
• Test tube dimensions: 25 × 170 mm
• Designed for filtering petroleum wax samples

Cooling Bath :

• Capacity: Three test tubes of 25 × 170 mm
• Insulated stainless steel tank with finished steel exterior
• Removable composition top plate
• Includes thermometer port, filling port, and three test tube ports
• Test tube port diameter: 25.4 mm (1 inch)
• Requires a suitable cooling mixture

Air Pressure Regulator :

• Mercury bubbler-type regulator
• Includes 250 mL glass cylinder, T-tube, and rubber stopper
• Controls airflow to the filter stick assembly

Evaporation Cabinet :

• Thermostatically controlled temperature: 35 ± 1°C (95 ± 2°F)
• Capacity: Four weighing bottles
• Provides a vertically downward airflow through glass jets
• Adjustable manifold for correct jet positioning
• Finished steel cabinet with composition front plate and hinged glass door

Standard Accessories :

• Filter Stick Assembly
• Air Pressure Regulator
• Four weighing bottles, 15 mL each

Dimensions (L × W × H) :

• Cooling Bath: 8 × 6 × 9 inches (20 × 15 × 23 cm)
• Evaporation Cabinet: 9 × 5 × 16 inches (23 × 13 × 41 cm)
• Overall dimensions: 24 × 20 × 18 inches (61.0 × 50.8 × 45.7 cm)

Net Weight :

• 8.2 kg (18 lbs)

Shipping Weight :

• 10.0 kg (22 lbs)

Optional Accessories :

• Mechanically Refrigerated Cooling Bath, 115 V, 60 Hz, ambient to −35°C
• Mechanically Refrigerated Cooling Bath, 220–240 V, 50/60 Hz, ambient to −35°C
• Test tube for outer filter stick body
• ASTM 71°F thermometer, range: −35 to +70°F

• Designed for petroleum wax oil content testing
• Includes filtration, cooling, air pressure regulation, and solvent evaporation assemblies
• Cooling bath accommodates three test tubes and filter stick assemblies
• Evaporation cabinet accommodates four weighing bottles
• Thermostatically controlled evaporation cabinet maintains a temperature of 35 ± 1°C (95 ± 2°F)
• Adjustable glass-jet manifold for positioning jets above the sample surface
