Open-cut automatic flash and fire point - Cleveland ASTM D8254 and ASTM D92 for developing and manufacturing laboratory test equipment

The automatic Cleveland open cup flash and fire point tester is designed to determine the flash point and fire point of petroleum products and lubricants under controlled laboratory conditions. It features a temperature range of 0C to 400C, ionization ring detection, and pre-installed testing methods for reliable operation. Manufactured by Atico Export with attention to precision, safety and functional requirements for petroleum testing equipment.

Temperature Range :

• 0C to 400C

Temperature Accuracy :

• 0.1C

Temperature Measurement :

• Angled glass probe

Detection System :

• Ionization ring detection

Testing Methods :

• Automatic
• Bitumen
• Manual
• Search mode for unknown flash points
• Standard testing methods pre-installed

Supplied With :

• Test cup
• PT100 sensor
• Electric ignitor
• Fixed intermediate insulating plate
• Movable upper insulating plate
• Metal plate

Options and Accessories :

• Surface skimmer
• Gas cartridge kit
• Protective screen
• Overflow cut-out

Safety Features :

• Automatic flame ignition
• Emergency stop
• Safety thermocouple
• Gas detection with audible alarm
• Automatic gas cut-off at the end of the test
• Automatic shutdown at the end of the test

Software and Data Management :

• Numeric keypad
• Password-protected calibration and service parameters
• Storage capacity for 200 results

Power Supply :

• 230 V, 50/60 Hz, 1000 W

Dimensions :

• Width: 330 mm
• Depth: 400 mm
• Height: 640 mm

Weight :

• 20 kg
