Penetrometer Bath for Oil and Petroleum Testing Equipment

The Constant Temperature Water Bath is designed for conditioning petroleum samples and other materials that require precise temperature control before or during penetration testing. It is suitable for use with manual and microprocessor-controlled penetrometers.

The bath features a transparent design for clear sample visibility and a large shelf that accommodates a wide range of sample containers, including those used in ASTM test procedures. Samples can remain in the bath during penetration testing when required. Digital temperature control maintains the liquid temperature with a stability of ±0.05°C. A dual-speed circulating pump ensures uniform temperature distribution, while an adjustable over-temperature thermostat and low-liquid cut-off provide operational safety.

Manufactured by Atico Export for dependable temperature conditioning and penetration testing in petroleum laboratories.

• Conditioning petroleum samples before penetration testing
• Maintaining sample temperature during penetration tests
• Testing lubricating greases, bitumens, petroleum waxes, and other suitable materials
• Use with manual and microprocessor-controlled penetrometers

Temperature Range :

• Ambient temperature to 70°C

Temperature Stability :

• ±0.05°C (±0.1°F)

Temperature Display :

• Large LED display
• Selectable Celsius and Fahrenheit units

Dimensions (L × W × H) :

• 45.7 × 33 × 21.6 cm (18 × 13½ × 8½ inches)

Net Weight :

• 10.9 kg (24 lbs)

• Transparent bath for clear visibility of samples
• Large shelf accommodates various sample containers
• Suitable for sample conditioning before and during testing
• Digital temperature control
• Dual-speed circulating pump for temperature uniformity
• LED temperature display with selectable °C and °F units
• Low-liquid safety cut-off
• Adjustable over-temperature protection
• Built-in cooling coil for refrigerated coolant or tap water circulation
• Compatible with manual and digital penetrometer arrangements
