Penetrometer Cones and Accessories for Oil and Petroleum Testing Equipment

Penetrometer accessories are designed to determine the consistency and hardness of petroleum products and other semi-solid materials. These accessories measure penetration depth using suitable cones, needles, plunger assemblies, sample containers, and related equipment. They support a wide range of standard test methods for petroleum waxes, bituminous materials, lubricating greases, petrolatum, food products, cosmetics, pastes, and other materials.

The range includes precision-machined cones and needles, sample containers, constant-temperature baths, grease workers, roll stability testers, and specialized accessories for different testing requirements.

Manufactured by Atico Export to support reliable consistency testing and quality control across petroleum testing and industrial laboratories.

• Needle penetration testing of petroleum waxes and paraffins
• Penetration testing of bituminous materials and asphalts
• Cone penetration testing of lubricating greases
• Consistency testing of petrolatum and petroleum jelly
• Roll stability testing of lubricating greases
• Testing of food products, fats, butter, margarine, chocolate, confectionery, dairy products, and viscous pastes
• Consistency testing of cosmetic creams, lipstick, and other semi-solid cosmetic products
• Testing of paints, varnishes, printing inks, putty, emulsions, and other pastes
• Specialized penetration testing of heterogeneous propellants

Available Accessories :

1. Petroleum Wax Penetration Accessories :

• Stainless steel needle, 2.5 g
• NIST-certified stainless steel needle, 2.5 g
• Brass wax specimen container with base plate
• Penetration bath

2. Bituminous Material Penetration Accessories :

• Stainless steel needle with brass ferrule, 2.5 g
• NIST-certified stainless steel needle with brass ferrule, 2.5 g
• Stainless steel needle with stainless steel ferrule, 2.5 g
• NIST-certified stainless steel needle with stainless steel ferrule, 2.5 g
• Sample container, 55 mm diameter × 35 mm depth, for penetration values below 200
• Sample container, 70 mm diameter × 45 mm depth, for penetration values between 200 and 350
• Transfer dish for submerging the sample container
• Penetration bath

Applicable Standards :

• ASTM D5
• IP 49
• DIN 52010

3. Lubricating Grease Cone Penetration Accessories :

• Magnesium cone with hardened stainless steel tip, 102.5 g
• Brass cone with hardened stainless steel tip, 102.5 g
• Grease worker
• Grease cutter for block penetration tests
• Penetration bath

4. Petrolatum Penetration Accessories :

• Magnesium cone with hardened stainless steel tip, 102.5 g
• Sample container with cover
• Penetration bath

5. Grease Roll Stability Accessories :

• Roll stability tester
• Quarter-scale aluminum cone, 2.48 g
• Quarter-scale grease worker

Applicable Standard :

• ASTM D1831

6. Half-Scale Grease Penetration Accessories :

• Half-scale stainless steel cone, 22.5 g
• Half-scale plunger, 15 g, for manual penetrometer use
• Half-scale grease worker
• Penetration bath

7. Quarter-Scale Grease Penetration Accessories :

• Quarter-scale aluminum cone, 2.48 g
• Quarter-scale plunger, 6.9 g, for manual or digital penetrometer use
• Quarter-scale grease worker
• Retaining base plate for mounting the grease worker on a bench or wall
• Blank lid with seal for the grease worker
• Penetration bath

8. Additional Penetration Cones :

• Magnesium cone, 15 g, for heterogeneous propellant testing
• Aluminum cone, 45 g, for fats, butter, and margarine testing
• Aluminum cone, 35 g, for paste testing
• Aluminum micro-cone, 5 g, for lubricating greases and cosmetic creams
• Pin needle for putty, fruit, and viscous pastes
• Hollow Plexiglass cone, 15 g, for yogurt and cream
• Perforated disk with cylindrical holes, 10 g, for puddings, gelatin, jam, and mustard

9. Food Industry Applications :

• Chocolate, confectionery, and yeast
• Putty, fruit, viscous pastes, and cheese
• Sausages and meat products
• Edible fats, butter, and margarine
• Pudding, jelly, yogurt, and mayonnaise
• Jam, marmalade, ketchup, mustard, and fruit preparations

10. Petroleum Industry Applications :

• Lubricating greases
• Vaselines and petrolatum
• Petroleum waxes and paraffins
• Bitumens and asphalts

11. Cosmetics Industry Applications :

• Lipstick and compact powder
• Face and skin creams
• Solid and semi-liquid cosmetic creams

12. Miscellaneous Industrial Applications :

• Pastes, emulsions, paints, and putty fillers
• Paints, varnishes, and printing inks
• Solid emulsions
• Specialized testing of heterogeneous propellants

Compatibility :

• Designed for use with compatible manual and digital penetrometers
• Supports a wide range of standardized test procedures
• Suitable for selected non-petroleum applications when the appropriate accessory and test method are used
