Penetrometer for Oil and Petroleum Testing Equipment

The Manual Penetrometer is designed to determine the consistency and penetration characteristics of petroleum products by measuring the depth to which a standard cone or needle penetrates a sample under specified time and temperature conditions. The standard test interval is 5 seconds, although other specified intervals may be used.

The instrument is precision-machined and ruggedly constructed for reliable operation in laboratory and field environments. It provides a penetration range of 0–62.0 mm with 1/10 mm subdivisions and accommodates cones and needles for testing lubricating greases, asphalts, petroleum waxes, petrolatums, and other solid to semi-solid materials.

Manufactured by Atico Export for dependable penetration testing and quality control applications.

• Consistency testing of lubricating greases
• Penetration testing of asphalts, petroleum waxes, and petrolatums
• Testing food products, cosmetics, pastes, and other semi-solid materials
• Petroleum product identification and quality control
• Laboratory and field testing

Penetration Range :

• 0–62.0 mm (0–620 penetration scale)

Scale Subdivision :

• 1/10 mm

Dimensions (L × W × H) :

• 15 × 15 × 46 cm (6 × 6 × 18 inches)

Net Weight :

• 6.4 kg (14 lbs)

Standard Accessories :

• Standard plunger assembly, 47.5 g
• Weights, 50 g and 100 g

Additional Accessories :

• Test cones and needles, ordered separately
• Lightweight plunger, where applicable

Applicable Standards :

• ASTM and related specifications for penetrometers

• Suitable for laboratory or field use
• Penetration range of 0–62.0 mm
• 1/10 mm scale subdivisions
• Compatible with standard test cones and needles
• Adjustable head assembly for accurate penetrator tip placement
• Sturdy cast iron base for stable support
• Built-in spirit level and leveling screws for proper alignment
• Compact design for convenient transportation
• Rugged construction for long service life
