Saybolt Viscosity Bath for Oil and Petroleum Testing Equipment

The Saybolt Viscometer Constant Temperature Bath is designed to determine the time required for 60 mL of a liquid sample to flow through a calibrated orifice under controlled temperature conditions. Saybolt Universal Seconds (SUS) are used for lubricants, insulating oils, and lighter fuel grades, while Saybolt Furol Seconds (SFS) are used for heavier oils and bituminous materials.

The bath features microprocessor-based PID temperature control to maintain temperature within specified tolerances. Dual digital displays allow convenient setting and monitoring of the bath temperature, with selectable Celsius or Fahrenheit readings. The system accommodates four viscometer tubes and four 60 mL receiving flasks. Its insulated stainless steel bath, removable chemical-resistant top plate, built-in overflow pipe, drain valve, and cooling coil support convenient operation and maintenance.

Manufactured by Atico Export for accurate viscosity testing and quality control in petroleum laboratories.

• Viscosity determination of lubricants and insulating oils
• Testing of lighter fuel grades
• Viscosity testing of heavy oils and bituminous materials
• Measurement using Saybolt Universal Seconds (SUS) and Saybolt Furol Seconds (SFS)

Capacity :

• Four viscometer tubes
• Four 60 mL receiving flasks

Temperature Range :

• Ambient temperature to 240°C (464°F)

Temperature Stability :

• ±0.03°C (±0.05°F)

Bath Capacity :

• 19 L (5 US gallons)

Recommended Bath Medium :

• Water or suitable heat-transfer fluid

Power Supply :

• 115 V, 60 Hz, single phase, 12.3 A
• 220–240 V, 50/60 Hz, single phase, 6.4 A

Dimensions (L × W × H) :

• 74 × 63.5 × 84 cm (29 × 25 × 33 inches)

Net Weight :

• 29.5 kg (65 lbs)

Standard Accessories :

• Cleaning plunger
• Oil strainer
• Tube nut wrench
• Port closures
• Chained corks
• Withdrawal tube
• Orifice wrench
• Port covers
• Thermometer supports

• Microprocessor-based PID temperature control
• Four viscometer tube capacity
• Accommodates four 60 mL receiving flasks
• Dual digital displays for temperature setting and monitoring
• Selectable Celsius or Fahrenheit temperature scale
• Two-place calibration offset
• Sliding draft shields for convenient sample handling
• Chemical-resistant alignment plate
• Glare-free fluorescent backlighting for sample visibility
• Heavy-gauge stainless steel bath interior
• Built-in overflow pipe and drain valve
• Removable, chemical-resistant insulated top plate
• Cooling coil for tap water or refrigerated coolant
• Steel cabinet with leveling feet and chemical-resistant finish
