Semi Automatic Ductility Testing Machine for Oil and Petroleum Testing Equipment

The Semi-Automatic Ductility Testing Machine is designed to determine the ductility and elastic recovery of bituminous materials. Ductility is measured by determining the distance a briquette specimen elongates before breaking when its ends are pulled apart at a specified speed and temperature.

For elastic recovery testing, the briquette specimen is stretched to a specified distance under controlled conditions and then cut. The distance required for the two halves to reconnect is used to determine the elastic recovery of the sample.

The machine features a 6-inch LCD touchscreen control panel that allows users to select pre-programmed ductility, recovery, and custom test methods. During testing, the distance travelled by the specimen is displayed, and the distance at breakage can be recorded directly through the touchscreen. A motor-jogging function helps position and lock the sample carriage after loading.

Manufactured by Atico Export for reliable ductility and elastic recovery testing in bitumen and asphalt testing laboratories.

• Determination of bitumen ductility
• Measurement of elastic recovery of bituminous materials
• Evaluation of elongation and breaking behaviour of briquette specimens
• Quality control testing of bitumen and asphalt materials
• Laboratory testing according to applicable ASTM standards

Capacity :

• Three moulds with samples

Maximum Travel Length :

• 150 cm

Standard Traction Speed :

• 5 cm/min

Variable Traction Speed :

• 0.25 to 7.0 cm/min

Timer :

• 1 to 999 minutes

Control Panel :

• 6-inch LCD touchscreen

Available Models :

Standard Model :

• Designed for ductility and elastic recovery testing
• Supplied with three standard moulds and a base plate

Constant-Temperature Model :

• Designed for testing under controlled temperature conditions
• Supplied with a circulation bath, remote temperature probe, connection tubing, three standard moulds, base plate, and Lexan cover

Standard Accessories – Standard Model :

• Standard moulds: 3
• Base plate

Standard Accessories – Constant-Temperature Model :

• Circulation bath
• Remote temperature probe, 10 ft length
• Connection tubing
• Standard moulds: 3
• Base plate
• Lexan cover

Dimensions (L × W × H) :

• Standard Model: 86.25 × 19 × 16 inches
• Constant-Temperature Model: 86.25 × 19 × 16 inches
• Circulation Bath: 15.75 × 8.25 × 22.5 inches

Net Weight :

• Standard Model: 91.7 kg (200 lbs)
• Circulation Bath: 22.7 kg (50 lbs)
• Constant-Temperature Model: 98.5 kg (217 lbs)

Shipping Weight :

• Standard Model: 159 kg (350 lbs)
• Constant-Temperature Model: 167 kg (368 lbs)

• Available in standard and constant-temperature models
• Capacity to test up to three specimens simultaneously
• 6-inch LCD touchscreen control panel
• Pre-programmed ductility, recovery, and custom test methods
• Maximum travel length of 150 cm
• Variable traction speed from 0.25 to 7.0 cm/min
• Standard traction speed of 5 cm/min
• Adjustable test speed and time parameters
• Displays specimen travel distance during testing
• Allows recording of the distance at specimen breakage
• Motor-jogging function for controlled sample carriage positioning
• Constant-temperature model supplied with a Lexan cover for improved temperature stability
