Semi-automatic flash point Pensky Martens ASTM D8175 and ASTM D93 for developing and manufacturing laboratory test equipment

The semi-automatic Pensky-Martens flash point tester is designed to determine the flash point of petroleum products and related liquids under controlled laboratory conditions. It features a temperature range from ambient temperature to 400C, four predefined testing methods, adjustable stirring speeds, and flexible sample preheating options. Manufactured by Atico Export with a focus on precision, durability and consistent performance in petroleum testing laboratories.

Temperature Range :

• Ambient temperature to 400C

Temperature Accuracy :
-0.2C

Temperature Measurement :

• Temperature units: C or F

Testing Methods :

• Method A
• Method A+
• Method B
• Method C
• Search mode
• Safety mode

Operating Features :

• Adjustable stirring speed from 0 to 250 rpm
• Sample preheating with or without stirring
• Predefined temperature ranges according to the selected method
• Fully electric ignition
• Mechanical fan cooling system
• Flash point detection using thermocouple

Supplied With :

• Lid with ignitor and thermocouple
• Test cup
• Power cable
• Stirring cable
• Stylus

Options and Accessories :

• RS232 ticket printer
• Calibration kit
• Stainless steel support for cover and lid

Safety Features :

• Electric ignitor protection through thermal fuse
• Dedicated alarm for each error message
• Audible alarm and visual indicator

Software and Data Management :

• User-friendly interface
• Predefined product information and testing rates
• Simplified temperature calibration
• Up to 5 calibration offsets
• Software updates through Micro-USB
• Data transfer or printing through RS232
• Memory for the last 20 results
• Password-protected access

Power Supply :

• 230 V, 50/60 Hz, 5 A

Dimensions :

• Width: 275 mm
• Depth: 440 mm
• Height: 250 mm

Weight :

• 10.5 kg
