Softening Point Apparatus for Oil and Petroleum Testing Equipment

The Ring and Ball Softening Point Apparatus is designed to determine the softening point of bituminous materials. The sample is cast into shouldered rings and heated at a controlled rate under the weight of steel balls. The softening point is recorded as the temperature at which the bitumen softens and sags downward by a specified distance.

Manufactured by Atico Export for reliable softening point determination in bitumen and asphalt testing laboratories.

• Determination of the softening point of bitumen
• Testing of bituminous materials used in road construction
• Quality control and evaluation of asphalt and bitumen products

Standard Accessories :

• 800 mL beaker
• Standard steel balls: 2
• Shouldered rings
• Ball-centering guides
• Ring holder
• Bottom plate
• Beaker cover with support rods

Dimensions (L × W × H) :

• 5 × 5 × 10.5 inches (12.7 × 12.7 × 26.7 cm)

Net Weight :

• 2.3 kg (5 lbs)

Additional Requirements :

• Thermometer
• Heater

• Suitable for ring and ball softening point testing
• Includes an 800 mL beaker
• Supplied with two standard steel balls
• Includes shouldered rings and ball-centering guides
• Ring holder and bottom plate included
• Beaker cover supplied with support rods
• Thermometer and heater are required separately
