Tag Open Cup Flash Tester for Oil and Petroleum Testing Equipment

The Tag Open Cup Flash and Fire Point Apparatus is designed to determine the flash and fire points of liquid products at temperatures up to 163°C (325°F) and the flash point of cutback asphalts below 93°C (200°F).

The apparatus includes a sample test cup, plated brass liquid bath with constant-level overflow, pivoting ignition taper with pilot light and reference bead, pivoting thermometer holder, heater, and cast aluminium base. The electrically heated model features stepless variable heat control to maintain the required temperature rise rate. A gas-heated version is also available.

Manufactured by Atico Export for reliable flash and fire point testing in petroleum and asphalt laboratories.

• Flash and fire point determination of liquid petroleum products
• Flash point testing of cutback asphalts
• Quality control testing of suitable flammable liquids

Test Temperature Range :

• Flash and fire points up to 163°C (325°F)
• Flash point testing of cutback asphalts below 93°C (200°F)

Heating Options :

• Gas heated
• Electrically heated

Power Supply :

• 115 V, 60 Hz, single phase, 13 A
• 220–240 V, 50/60 Hz, single phase, 0.6 A

Dimensions (W × D × H) :

• 25.4 × 44.5 × 29.2 cm (10 × 17.5 × 11.5 inches)

Net Weight :

• 9.1 kg (20 lbs)

Standard Accessories :

• Sample test cup
• Borosilicate glass sample cup
• Plated brass liquid bath
• Ignition taper with pilot light and reference bead
• Thermometer holder

• Tag Open Cup testing method
• Available with gas or electric heating
• Plated brass liquid bath with constant-level overflow
• Pivoting ignition taper with pilot light and reference bead
• Pivoting thermometer holder for convenient positioning
• Stepless variable heat control on the electrically heated model
• Cast aluminium base for stable support
