Vapor Pressure of Crude Oil & Petroleum Products for Oil and Petroleum Testing Equipment

The Automatic Vapor Pressure Analyzer is designed to determine the vapor pressure of volatile liquid petroleum products, including crude oil, gasoline, jet fuel, solvents, hydrocarbons, and hydrocarbon-oxygenate mixtures. It is suitable for analyzing automotive spark-ignition fuels with or without oxygenates.

The instrument operates using a benchtop design with one-button operation. The sample is introduced into a nickel-plated aluminum chamber, where its temperature is controlled using a Peltier thermoelectric device. A high-resolution pressure transducer continuously monitors pressure and compensates for variations. An integrated touchscreen provides convenient instrument control and operation.

The analyzer supports automatic sample introduction through an internal piston and valve system and can accommodate a siphon tube, syringe, or pressurized cylinder. It also includes integrated sample shaking, data storage, and multiple communication and output interfaces.

Manufactured by Atico Export for reliable vapor pressure analysis and quality control in petroleum testing laboratories.

• Vapor pressure determination of crude oil and petroleum products
• Testing of gasoline and automotive spark-ignition fuels
• Analysis of jet fuel, solvents, and volatile hydrocarbons
• Testing of hydrocarbon-oxygenate mixtures
• Quality control and evaluation of petroleum fuels
• Laboratory testing according to applicable ASTM and international standards

Temperature Range :

• 0 to 100°C (32 to 212°F)

Temperature Stability :

• ±0.01°C (±0.02°F)

Pressure Range :

• 0 to 1000 kPa (0 to 145 psi)

Pressure Resolution :

• 0.01 kPa (0.0014 psi)

Sample Volume :

• ≤1 mL
• Rinse cycle volume: 2.5 mL

Vapor-to-Liquid Ratio :

• Adjustable from 0.2:1 to 100:1

Measurement Time :

• Approximately 5 minutes for standard methods

Interfaces :

• USB Type-A and Type-B
• RS232
• Ethernet

Dimensions (L × W × H) :

• 11.5 × 11.5 × 15.5 inches (30 × 30 × 40 cm)

Net Weight :

• 11.4 kg (25 lbs)

Standard Accessories :

• Line cord
• Waste disposal container
• Piston oil, 125 mL bottle
• Sample inlet assembly
• Mesh filter set: 100-micron and 200-micron filters, two each

• Integrated sample shaker with locking mechanism
• Fully automatic sample introduction through an internal piston and valve system
• Compatible with a siphon tube, syringe, or pressurized cylinder
• Nickel-plated aluminum measuring chamber
• Peltier thermoelectric temperature control
• High-resolution pressure transducer with continuous pressure monitoring
• Integrated touchscreen for convenient operation
• Storage capacity for more than 50,000 analyses
• Data output through LIMS, network, ticket printer, full-page printer, and USB interfaces
• USB Type-A, USB Type-B, RS232, and Ethernet connectivity
• Measurement time of approximately 5 minutes for standard methods
