Wax Melting Point Apparatus for Oil and Petroleum Testing Equipment

The Wax Melting Point Apparatus is designed to determine the melting point of petroleum wax using the cooling curve method. Periodic temperature measurements are taken as a molten wax sample cools in an air bath. When the wax solidifies, a plateau appears on the cooling curve, indicating the melting point of the sample.

The apparatus consists of a nickel-plated air and water bath assembly with a removable cover. It supports the test tube vertically in the air bath for controlled cooling and temperature measurement.

Manufactured by Atico Export for reliable melting point determination and quality evaluation of petroleum waxes.

• Determination of the melting point of petroleum wax
• Evaluation of wax solidification characteristics
• Quality control and testing of petroleum wax products
• Laboratory analysis using the cooling curve method

Standard Accessories :

• Test tube
• Thermometer holders: 2

Dimensions :

• Diameter × Height: 5.5 × 7 inches (14 × 18 cm)

Net Weight :

• 1.8 kg (4 lbs)

Shipping Weight :

• 2.7 kg (6 lbs)

Shipping Volume :

• 0.7 cubic feet

• Designed for the cooling curve method
• Nickel-plated air and water bath assembly
• Removable cover for convenient operation
• Holds the test tube in a vertical position
