Current Meter Teaching Equipment

Current Meter is designed for universal river flow measurement applications and can be used as a rod-mounted current meter or in a suspended configuration. It is suitable for practical measurement of flow velocity and discharge in rivers and open water channels.

The instrument can be used with a single-drum winch in combination with a bridge jib or measurement trolley, as well as with a double-drum winch for cable-way installations.

The current meter is also suitable for calibration and cyclical control of flow velocity and discharge measuring equipment. Its stainless-steel meter body and pressure-tight magnetic switch provide reliable operation in demanding water measurement environments.

Manufactured by Atico Export with a focus on precision, durability and consistent performance for technical education and practical training applications.

Measurement :

• Measuring range: 0.025–10 m/s
• Current meter output: 1 pulse/revolution

Electrical :

• Operating voltage: maximum 9 V DC
• Reed relay contact lifetime: >1 million switching contacts
• Magnetic switch: pressure-tight up to 30 bar

Construction :

• Meter body: Stainless steel
• Propeller: Aluminium
• Alternative propeller: Plastic, Hostaform C, yellow
• Dimensions (diameter × length): approximately Ø35 × 310 mm
• Weight without propeller: 1.26 kg

• Universal application for river flow measurements
• Rod-mounted or suspended configuration
• Compatible with single-drum winch and bridge jib/measurement trolley
• Suitable for double-drum winch cable-way installations
• Calibration of flow velocity and discharge measuring equipment
• Cyclical control of flow velocity and discharge measuring equipment
• Current meter with 1 pulse per revolution
• Reed relay contact lifetime: >1 million switching contacts
• Pressure-tight magnetic switch up to 30 bar
• Stainless-steel meter body
• Aluminium propeller
• Alternative plastic propeller available
• Hostaform C, yellow
