Extraction Process Study Teaching Equipment

Extraction Process Study is designed for practical laboratory investigation of solid-liquid extraction processes. The equipment provides a hands-on platform for studying the principles of solvent extraction and evaluating the influence of temperature, particle size and mixing on extraction efficiency.

The system enables students to investigate both cold and hot solvent extraction processes and determine the efficiency of extraction when changing the size of solid particles. The effect of mixing on the extraction process can also be studied under controlled laboratory conditions.

A program-controlled photocolorimeter is provided for determining the optical density of solutions, while a sample grinder, temperature sensor, electronic unit and control panel support the experimental process. The equipment can also be connected to a laptop for data handling and analysis.

Designed and manufactured by Atico Export to meet the practical requirements of modern technical education laboratories.

Laboratory Experiments :

• Study of the cold solvent extraction process
• Study of the hot solvent extraction process
• Determination of extraction efficiency when changing the size of solid particles
• Determination of extraction efficiency with the mixing process
• Determination of optical density of solutions using a digital photocolorimeter

Technical Details :

• Extractor for carrying out solid-liquid extraction experiments
• Sample grinder for preparing solid materials with different particle sizes
• Temperature sensor for monitoring extraction temperature
• Program-controlled photocolorimeter for optical density measurement
• Electronic unit and control panel for system operation
• Laptop connectivity for experimental data handling

Power Specifications :

• Power supply: 220 V ±10%, 50 Hz
• Power cable: European standard

Dimensions and Weight :

• Height: 1000 mm
• Width: 500 mm
• Depth: 500 mm

Delivery Set :

• Extraction Process Study Laboratory Equipment – 1 set

• Metal aluminum frame base with fastening to the laboratory table
• Laboratory table
• Extractor
• Program-controlled photocolorimeter
• Sample grinder
• Temperature sensor
• Electronic unit and control panel
• Laptop connection capability
• Complete delivery set compatible with the required design and functionality
