Fluidization Process Study Teaching Equipment

Fluidization Process Study is designed for practical laboratory investigation of fluidization processes and the formation of two-phase flows involving air and granular materials. The equipment provides a hands-on platform for studying the behavior and main characteristics of fluidized beds under different air flow conditions.

The system enables experimental determination of relationships between the characteristic parameters of the fluidization process and the flow rate, density, particle size, particle shape and initial height of the granular layer.

Students can investigate the structure of the granular layer as a function of air flow velocity and determine the relationship between pressure drop across the material layer and air flow velocity. The equipment is suitable for chemical engineering, process engineering and fluid mechanics laboratories.

Manufactured by Atico Export with a focus on precision, durability and consistent performance for technical education and practical training applications.

• Metal aluminum frame
• Fluidization column
• Compressor
• Flow meter
• Pressure sensor
• Frequency transducer
• Electronic control unit
• Special software with interface in Russian and/or English
• All markings, nameplates and inscriptions on the casing in English and/or Russian
• Complete delivery set compatible with the required design and functionality

Laboratory Experiments :

• Study of the properties and main regularities of the formation of two-phase flows during the fluidization process
• Experimental determination of criteria relationships connecting characteristic process parameters with flow rate, density, particle size and shape, and initial layer height
• Study of the structure of the granular layer depending on air flow velocity
• Determination of the dependence of pressure drop across the material layer on air flow velocity

Technical Details :

• Fluidization column for studying granular material behavior
• Compressor for supplying fluidizing air
• Flow meter for measuring air flow
• Pressure sensor for measuring pressure drop
• Frequency transducer for flow control
• Electronic control unit for system operation and control

Dimensions and Weight :

• Height: 700 mm
• Width: 550 mm
• Depth: 700 mm

Delivery Set :

• Fluidization Process Study Laboratory Equipment – 1 set
• Computer connecting cables – 1 set
• Special software – 1 set
• Description of possible laboratory works with the equipment in Turkish – 1 set
• Required accessories or equipment for operation will be supplied by the manufacturer
• Laptop is not included
