Fluke Multifunction Installation Tester

Multifunction Installation Tester is designed for comprehensive electrical installation testing and commissioning applications. It provides fast high-current loop testing, variable RCD current testing, voltage measurements and loop and line resistance measurements.

The tester supports RCD testing for different RCD types, including general, time-delayed, pulsed-signal, AC and Type B RCDs. It provides PASS/FAIL indication for RCD tests and supports customized current settings.

The instrument provides continuity testing, insulation resistance measurement with test voltages from 50 V to 1000 V, loop impedance measurement in high-current and non-trip modes, PFC/PSC testing, earth resistance measurement and phase sequence indication.

Extended memory and documentation functions support recording and reporting of measurement results. A zero adapter is provided for easy test lead compensation.

Manufactured by Atico Export with a focus on precision, durability and consistent performance for technical education and practical training applications.

AC Voltage Measurement :

• Range: 500 V
• Resolution: 0.1 V
• Accuracy (50–60 Hz): ±(0.8% + 3 digits)
• Input impedance: 3.3 MΩ
• Overload protection: 660 V RMS

Continuity Testing :

• Auto-ranging: 20 Ω, 200 Ω, 2000 Ω
• Resolution: 0.01 Ω, 0.1 Ω, 1 Ω
• Test current: >200 mA
• Open-circuit voltage: >4 V
• Accuracy: ±(1.5% + 3 digits)

Insulation Resistance Measurement :

• Test voltages: 50 V, 100 V, 250 V, 500 V and 1000 V
• Test current: 1 mA at corresponding nominal test resistance
• Insulation range: 10 kΩ–50 MΩ
• Resolution: 0.01 MΩ
• Accuracy: ±(3% + 3 digits) for applicable ranges
• 100 V range/resolution: 20 MΩ / 0.01 MΩ and 100 MΩ / 0.1 MΩ
• 250 V range/resolution: 20 MΩ / 0.01 MΩ and 200 MΩ / 0.1 MΩ
• 500 V range/resolution: 20 MΩ / 0.01 MΩ, 200 MΩ / 0.1 MΩ and 500 MΩ / 1 MΩ
• 1000 V range/resolution: 20 MΩ / 0.01 MΩ, 200 MΩ / 0.1 MΩ and 500 MΩ / 1 MΩ
• Accuracy for applicable 250–1000 V ranges: ±(1.5% + 3 digits)
• Accuracy for 500 MΩ / 1 MΩ range: 10%
• Auto discharge: discharge time constant of 0.5 s for C = 1 µF or less
• Live circuit detection: inhibits test if terminal voltage is >30 V before test initiation
• Maximum capacitive load: 5 µF

Loop Impedance Measurement :

• Measurement modes: High Current and Non-Trip
• Range: 100–500 V AC, 50/60 Hz
• Input connection: Soft-key selection
• Loop impedance: Phase to earth
• Line impedance: Phase to neutral
• Automatic thermal shutdown after 50 consecutive tests at 10-second intervals (typical)
• Maximum test current at 400 V: 20 A sinusoidal for 10 ms
• Maximum test current at 230 V: 12 A sinusoidal for 10 ms
• Range/resolution: 20 Ω / 0.01 Ω
• Range/resolution: 200 Ω / 0.1 Ω
• Range/resolution: 2000 Ω / 1 Ω
• Accuracy in Non-Trip mode: ±(3% + 6 digits)
• Accuracy in High Current mode: ±(2% + 4 digits)

PFC / PSC Test :

• PFC or PSC determined from measured mains voltage and loop or line resistance
• Range: 0–25 kA
• Resolution for Ik <1000 A: 1 A
• Resolution for Ik ≥1000 A: 0.1 kA
• Accuracy: determined by the accuracy of loop resistance and mains voltage measurements

RCD Testing :

• General RCD: no delay
• S: time delay
• A: responds to pulsed signals
• AC: responds to AC
• B: responds to AC up to 1000 Hz and AC superposed by DC

RCD Tripping Time Test :

• Trip time accuracy: ±(1% of reading + 1 digit)
• Multipliers: ×½, ×1 and ×5
• Current settings: 10, 30, 100, 300, 500 and 1000 mA
• Current accuracy for ×½: +0% to −10%
• Current accuracy for ×1: +10% to −0%
• Current accuracy for ×5: ±10%
• RCD Type G measurement range:
  • ×½: 310 ms (Europe), 2000 ms
  • ×1: 310 ms
  • ×5: 50 ms
• RCD Type S measurement range:
  • ×½: 510 ms (Europe), 2000 ms
  • ×1: 510 ms
  • ×5: 160 ms

RCD Tripping Current (Ramp) :

• Current range: 50%–110% of rated residual current
• Step size: 10% of IΔN
• Dwell time, Type G: 300 ms/step
• Dwell time, Type S: 500 ms/step
• Trip current measurement accuracy: ±5%

Earth Resistance Test :

• Range/resolution: 200 Ω / 0.1 Ω
• Accuracy: ±(2% + 5 digits)
• Range/resolution: 2000 Ω / 1 Ω
• Accuracy: ±(3.5% + 10 digits)
• Frequency: 128 Hz
• Compliance voltage: +25 V

Phase Sequence Indication :

• Phase sequence indicator
• Digital display of phase sequence
• Correct sequence: 1-2-3
• Incorrect sequence: 3-2-1
• Dashes are displayed when a valid determination cannot be made

• Fast high-current loop test
• Variable RCD current mode for customized settings
• PASS/FAIL indication for RCD tests
• Selectable voltage measurement between L-N, L-PE and N-PE
• Zero adapter for easy test lead compensation
• Loop and line resistance measurement
• Testing of Type B and other sensitive RCDs
• Extended memory
• Extended documentation mode
• AC voltage measurement
• Continuity testing
• Insulation resistance measurement
• Loop impedance measurement in high-current and non-trip modes
• PFC and PSC testing
• RCD testing
• RCD tripping time test
• RCD tripping current ramp test
• Earth resistance testing
• Phase sequence indication
