+91 98967 93832Convection is one of the three basic forms of heat transfer in which heat is transported through the movement of a fluid. This teaching equipment is designed for practical study and demonstration of free and forced convection using different heating elements and surface geometries.
The system features a vertical air duct through which ambient air is guided by a speed-controlled axial fan. Heating elements can be positioned inside the air duct for forced convection experiments, while selected heating elements can also be operated outside the air duct to investigate free convection. The heating elements are designed to release heat primarily through their surfaces, allowing efficient heating and practical experimentation.
The equipment includes multiple temperature sensors at the air duct inlet and outlet and an air velocity sensor for determining airflow. Heating power and airflow can be adjusted and monitored through the data acquisition system and user interface.
The system supports experiments involving free and forced convection, heat transfer comparison on different surfaces, heat distribution, Reynolds and Nusselt number calculations, heat transfer coefficients and heat transfer rates.
Manufactured by Atico Export with a focus on precision, durability and consistent performance for technical education and practical training applications.
Specifications :
Experiments :
Data Acquisition :
Required for Operation :
